Lockly SECURE LATCH EDITION Installation Manual page 12

Step 5
Interior
Positioning rods slide
through these holes.
V
LK
Mounting Plate
11
INSTALLING THE LOCK (INTERIOR)
1
Insert Positioning Rods
to the left and right of the Spindle
The holes are located at the 3 o'clock
and 9 o'clock positions.
2
Interior Mounting Plate
the interior side of your door. Remove
the paper layer off of the Adhesive Tape
and align the positioning rods on the bottom
of the plate to the corresponding left and
right holes.
Install the side with the black plastic seal
against the door.
V
into the holes
C
.
LK
will go against
