Single Monitor Wall Mount + Keyboard Tray Wall
Mount + PC Wall Mount
Instruction Manual
SKU: MOUNT-VWKB1P
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-vwkb1p
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-VWKB1P
Summary of Contents for Vivo MOUNT-VWKB1P
- Page 1 Single Monitor Wall Mount + Keyboard Tray Wall Mount + PC Wall Mount Instruction Manual SKU: MOUNT-VWKB1P Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-vwkb1p GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. -
Page 3: Tools Needed
TOOLS NEEDED Phillips Level Drill Pencil Socket Wrench Stud Finder Screwdriver ASSEMBLY STEPS STEP 1 Loosen the screw on Wall Mount (A) and slide off VESA Plate (A1). STEP 2 Place Wall Mount (A) against the wall at the desired location and mark drilling locations with a pencil. Use of a level is recommended. - Page 4 STEP 3 Assemble VESA Plate (A1) to the back of the monitor using Screws (M-A or M-B) and M5 Washers (M-C). STEP 4 Slide VESA Plate (A1) back into Wall Mount (A) and secure by retightening the screw. Raise the monitor by lifting up.
- Page 5 STEP 5 Wood Stud Installation Brick/Concrete Installation Use Arm (B) to mark mounting locations. Use of Use Arm (B) to mark mounting locations. Using a level and stud finder is recommended. Using a a 3/8” (10mm) bit, drill holes 2.4” (60mm) deep. 3/16”...
- Page 6 STEP 6 Insert Covers (G) into the mounting holes in Arm (B). STEP 7 Assemble Keyboard Tray (C) using Keyboard Tray Bracket (D) with M4x8mm Screws (S-A) and a Phillips screwdriver. STEP 8 Mount the keyboard tray assembly to Arm (B) using M4x12mm Flat Head Screws (S-B) and M4 Nuts (S-C).
- Page 7 STEP 9 Remove the adhesive backing from Wrist Pad (F) and place it on Keyboard Tray (C) along with Mouse Pad (E). STEP 10 Route cables through the cable management channels in Arm (B). Adjust the tilt of Arm (B) using 6mm Allen Wrench (T-A).
- Page 8 STEP 11 Remove the nuts from PC Mount (H) and separate into Wall Bracket (H1), End Bracket (H2) and Washers (H3).
- Page 9 STEP 12 Wood Stud Installation: Place the Wall Bracket (H1) against the wall and mark drilling locations with a pencil. Use of a stud finder and level is recommended. Drill 1.8” (45mm) deep hole(s) using a 1/8” (3mm) bit. Thread the “T” end of each Strap (I) into the slots in the Wall Bracket (H1), then mount the Wall Bracket using ST4.2x45 Screws (W-F) with Small M5 Washers (W-I).
- Page 10 STEP 14 Reassemble the end bracket (H2) and Washers (H3) to the Wall Bracket (H1) using Knobs (S-D), leaving slightly loose for later adjustment. Thread the end of each Strap (I) through the slots in the end bracket, then back up into the clip on each strap as shown.
- Page 11 STEP 15 Place the PC tower into PC Mount (H), then adjust the end bracket to fit and tighten knobs (S-D). Tighten Straps (I), thread the ends into the buckles on the straps, and close the buckles to secure.
- Page 12 : 1HR 8M help@vivo-us.com (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
