- Page 1 Rotating TV Wall Mount MOUNT-VW080P Assembly Manual...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Failure to report missing parts within 30 days may result in denial of free replacement.
-
Page 3: Package Contents
Package Contents A (x1) B (x2) Mount VESA Bracket Included Hardware & Tools S-A (x4) S-B (x4) M-A (x4) M-B (x4) M-C (x4) M6x12mm M6 Nut M6x14mm M8x16mm M6x30mm Screw Screw Screw Screw M-D (x4) M-E (x4) M-F (x4) M-G (x4) M8x35mm M8 Small Washer Small Spacer... -
Page 4: Assembly Steps
Assembly Steps STEP 1 Separate Mounting Plate (A1) from Mount (A). -
Page 5: Option 1: Wood Stud Installation
STEP 2 Option 1: Wood Stud Installation Using the center holes on Mount (A) and a pencil, mark drilling locations. Use of of a level and stud finder is recommended. Pre-Drilling Instructions Drill mounting holes using illustration shown Drill Bit: 3/16” (4.5mm) Hole Depth: 2.4”... - Page 6 Option 1 - Cont’d Secure Mount (A) to the wall using ST6.3x50 Screws (W-D) into the upper two holes using a Phillips screwdriver. Install ST8x60mm Screw (W-A) with M8 Large Washer (W-C) into the lower hole using a 10mm socket wrench. Arrow Ensure Arrow on Mount (A) is pointing up.
-
Page 7: Option 2: Concrete Installation
Option 2: Concrete Installation Pre-Drilling Instructions Drill mounting holes using illustration shown Drill Bit: 1/2” (12mm) Mark drilling locations in a triangle Hole Depth: pattern using a pencil. Use of a level is 2.6” (65mm) recommended. Press Concrete Anchors (W-B) into the drilled holes. Secure Mount (A) to the wall using ST8x60mm Screws (W-A) with M8 Large Washers (W-C) and a 10mm socket wrench. - Page 8 STEP 3 Attach VESA Brackets (B) to Mounting Plate (A1) using M6x12mm Screws (S-A) with M6 Nuts (S-B) and Wrench (T-A) according to the VESA pattern height of your TV. Attach VESA Brackets (B) to the back of TV using appropriate Screws (M-A thru M-D) and Washers (M-E).
- Page 9 STEP 4 Gently slide Monitor into the Mount (A) as shown. 2 Person Mounting Recommended...
- Page 10 Rotating the TV Pull down on the Locking Cable on the bottom of Mount (A) to allow rotation of the TV. Locking Cable Note: The mount auto-locks at each 90 degree position.
- Page 11 Love Your New Setup? Tag Us on Social! @ VIVO-us @ vivo_us @VIVOus VIVO...
- Page 12 Need Help? We’re Here For You Monday-Friday from 7am-7pm CST Saturday 8am-4pm CST Email Us Chat with Live Agent Give Us a Call help@vivo-us.com www.vivo-us.com 309-278-5303 ext. 1 FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us @VIVOus VIVO...
