Summary of Contents for Vivo MOUNT-VC86-5
- Page 1 TV Ceiling Mount with 5.5ft Pole SKU: MOUNT-VC86-5 Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/mount-vc86-3...
-
Page 2: We're Here For You
If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Package Contents
Package Contents A (x1) B (x1) C (x1) D (x1) Upper Pole Lower Pole Mounting Template Plate E (x1) F (x2) G (x2) H (x2) Pole Bracket VESA Bracket Cover Included Hardware & Tools S-A (x4) S-B (x2) S-C (x2) T-A (x1) M6x8mm Screw M8x55mm Screw... -
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Adjust the Ceiling Bracket on Upper Pole (A) to the angle of your ceiling using 5mm Allen Wrench (T-B) and Wrench (T-C). CEILING Ceiling Bracket STEP 2 Slide the Pole Bracket (E) down Lower Pole (B), ensuring the two Mounting Notches on the end of the Pole Bracket are pointing upward. - Page 5 STEP 2 Cont’d Secure the assembly by tightening the Locking Screw on the back of the Pole Bracket using the 5mm Allen Wrench (T-B). Locking Screw STEP 3 Attach Lower Pole (B) to Upper Pole (A) at the desired height using M8x55mm Screws (S-B) and M8 Nuts (S-C).
- Page 6 STEP 4 Option 1: Wood Stud Mounting Use Template (D) and a Pencil to mark drilling locations on the ceiling where a stud is located. Using a stud finder is recommended. Pre-Drilling Instructions Drill marked mounting holes using illustration below. 1/4”...
- Page 7 Wood Stud Mounting Cont’d Secure Upper Pole (A) to the ceiling using ST8x90mm Screws (W-A), Large M8 Washers (W-C) and a 13mm Socket wrench. 2 Person Mounting is Recommended Place Covers (H) over the Ceiling Bracket. Ceiling Bracket Proceed to STEP 5 on Page 10...
- Page 8 Option 2: Concrete/Brick Mounting Use Template (D) and a Pencil to mark drilling locations on the ceiling where a stud is located. Using a stud finder is recommended. Pre-Drilling Instructions Drill marked mounting holes using illustration below. 1/2” (12mm) Drill Bit 3.7”...
- Page 9 Concrete/Brick Mounting Cont’d Press Concrete Anchors (W-B) into the drilled holes. Secure Upper Pole (A) to the ceiling using ST8x90mm Screws (W-A), Large M8 Washers (W-C) and a 13mm Socket wrench. 2 Person Mounting is Recommended Place Covers (H) over the ceiling bracket.
- Page 10 STEP 5 Partially loosen the preinstalled screws on Mounting Plate (C) using the 4mm Allen Wrench (T-A). Attach Arms (F) to Mounting Plate using M6x8mm Screws (S-A). Tighten all screws using the 4mm Allen Wrench. Flip the Mounting Plate assembly over and loosen the pair of nuts using Wrench (T-C) leaving a 3mm gap.
- Page 11 STEP 6 Hang Mounting Plate (C) onto the Pole Bracket (E). Use Wrench (T-C) to tighten the previously loosened nuts and reinstall the previously removed nut.
- Page 12 STEP 7 Attach VESA Brackets (G) to the back of your TV using appropriate Screws (M-A~M-D), Washers (M-E) and Spacers (M-F,M-G). Security Screw The ends of the VESA Brackets with preinstalled Security Screws point toward the bottom of TV Too Long Too Short...
- Page 13 STEP 8 Loosen the Security Screws on both VESA Brackets (G) with a Phillips screwdriver. Security Screw Hang the TV onto the arms on the Mounting Plate (C). Secure by tightening the Locking Screws on both VESA Brackets. 2 Person Mounting is Recommended...
-
Page 14: Tilt Adjustments
Tilt Adjustments For vertical tilt adjustment, adjust the screws on the side of the Pole Bracket (E) using Wrench (T-C). For horizontal tilt adjustment, adjust the screw on back of Pole Bracket using 5mm Allen Wrench (T-B). For side-to-side tilt adjustment, adjust the top screws on the back of the Mounting Plate (C) using Wrench (T-C). - Page 15 [ THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK ]...
-
Page 16: Last Updated
LAST UPDATED: 07/10/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
