White VESA Adapter Bracket for 2 Monitor Screens
Instruction Manual
SKU: MOUNT-VW02AW
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-vw02a
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo MOUNT-VW02AW
Summary of Contents for Vivo MOUNT-VW02AW
- Page 1 White VESA Adapter Bracket for 2 Monitor Screens Instruction Manual SKU: MOUNT-VW02AW Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-vw02a GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
CAUTION! DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO MOUNT. We include mounting for brick and concrete walls. If unsure, please contact us at vivo-us. com, email at help@vivo-us.com, or call us at 309-278-5303. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Attach arms (C) to brackets (B) and (D) using bolts (H) and 4mm allen key (I) as shown in diagram. STEP 2 Slide VESA brackets (A) onto arms (C). Attach end caps (F) to arms and secure using bolts (G). Secure VESA brackets (A) using 4mm allen key (I). - Page 4 STEP 3 Attach cable clips (E). STEP 4A-1 Secure assembly to existing VESA plate using bolts (M-B) washers (M-C) and nuts (M-D) as shown in diagram. M- D M- C M- B...
- Page 5 STEP 4A-2 Thread bolts (M-A, M-B) and washers (M-C) into top two holes on each monitor making sure to leave 3mm of threads exposed. Slide monitors onto VESA plates and secure bottom two holes on each using bolts (M-A, M-B) and washers (M-C). 3m m M- C M- A...
- Page 6 STEP 4B-1 Thread bolts (M-A, M-B) and washers (M-C) into top two holes on each monitor making sure to leave 3mm of threads exposed. Slide monitors onto VESA plates and secure bottom two holes on each using bolts (M-A, M-B) and washers (M-C). 3m m M- C M- A...
- Page 7 STEP 4B-3 Adjust monitors using 6mm allen key (J). Adjust as Desired...
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
