1. Position access controller module over corresponding spacers and depress onto snap on spacers (Fig. 4, pg. 5).
2. Mount backplane to enclosure with hardware.
Access Controller Position Chart for the Following Models:
LenelS2 / Mercury Access Controller
LNL-1320 / MR52
Fig. 4
Altronix eFlow104NB
L G N
RSB1
PWR1 +
PWR2 +
Altronix ACMS8(CB)
Altronix VR6 is mounted under ACMS8(CB)
Altronix PDS8(CB)
(D) LNL-1320,
MR52
IN1 IN2 IN3 IN4 IN5 IN6 IN7 IN8
INPUTS
T2M7CK Kit Installation Guide
T2M7CK3(D) Configuration:
PWR1 +
PWR2 +
PN
REV
SN
RS-485 12V
(A) LNL-1320,
MR52
PN
IN1 IN2 IN3 IN4 IN5 IN6 IN7 IN8 REV
SN
INPUTS
(B) LNL-1320,
MR52
PN
IN1 IN2 IN3 IN4 IN5 IN6 IN7 IN8
REV
SN
INPUTS
(C) LNL-1320,
MR52
PN
IN1 IN2 IN3 IN4 IN5 IN6 IN7 IN8 REV
SN
INPUTS
Pem Mounting
A B C D
RS-485 12V
RS-485 12V
RS-485 12V
