- Page 1 POS-8717U Full Flat Touch Screen POS System User Manual Installation Guide Copyright © 2023 Fametech Inc. All Rights Reserved. All other brands, product names, company names, trade names, trademarks and service marks used herein are the property of their respective owners.
-
Page 2: Table Of Contents
Contents General Information Revision History About This Manual Disclaimer Warning Caution Warranty Limits Trade Marks and Service Marks Important Safety Information Product Overview Packing Specifications Dimension Part Description I/O Ports POS Installation Unpack Your POS Install Your POS Plug AC Power Cord to the POS Install the Rear Top Mount Customer Display (Optional) Replace Hard Disk Copyright ©... -
Page 3: General Information
General Information Revision History Date Version Update Summary Remark Approved By 2021/06/07 V1.0 Initial Release Harrel Chen Robert Kuo 2023/06/28 V1.1 Add i5-7267U, and delete Ariel Chiu Max Liang i5-6360U Processor Copyright © 2023 Fametech Inc. All Rights Reserved. All other brands, product names, company names, trade names, trademarks and service marks used herein are the property of their respective owners. -
Page 4: About This Manual
About This Manual The purpose of this user’s manual is to provide general information on TYSSO’s POS Terminal and to show the users how to configure the hardware-related configurations. The information in this manual is subject to change without notice due to rapid improvement on IT technology. Users can get the most up to date information from our web sites: http://www.fametech.com.tw... -
Page 5: Caution
Warranty does not cover any damage caused by improper use. Trade Marks and Service Marks TYSSO is a registered trademark of FAMETECH INC. Other brand and product names are trademarks and registered trademarks and service marks of their respective owners. -
Page 6: Important Safety Information
Important Safety Information Read following instructions carefully. Use only parts, especially power adapter, recommended by the manufacturer; unapproved parts may be hazardous. Before plugging the power cord into the AC inlet of the power supply unit, make sure ... -
Page 7: Product Overview
Product Overview Packing POS Unit Power Adapter AC Power Cord Quick Installation Guide Contents POS Unit Power Adapter (External, hidden under base) AC Power Cord Quick Installation Guide RJ-45 to RS-232 Cable Optional Accessories* Magnetic Stripe Card Reader (MSR) ... -
Page 8: Specifications
Specifications Model POS-8717U 7th Generation Kaby Lake Processor Intel® Core™ i5-7267U Processor (3M Cache, 2.30 GHz) Memory 2 x DDR4 SODIMM, up to 32GB Storage 1 x M.2 SATA SSD (Option : M.2 PCIe SSD and 2.5" HDD/SSD) 17-inch TFT LCD with LED Backlight... -
Page 9: Dimension
Dimension Left View Front View Right View Rear View Bottom View Copyright © 2023 Fametech Inc. All Rights Reserved. All other brands, product names, company names, trade names, trademarks and service marks used herein are the property of their respective owners. -
Page 10: Part Description
Part Description Front View MSR Module (Optional) Touch Screen Base Power Indicator Rear View MSR Module (Optional) HDD Cover Side I/O Ports Base Rear Cover Copyright © 2023 Fametech Inc. All Rights Reserved. All other brands, product names, company names, trade names, trademarks and service marks used herein are the property of their respective owners. - Page 11 Bottom View (POS Unit) Bottom View (Base) Copyright © 2023 Fametech Inc. All Rights Reserved. All other brands, product names, company names, trade names, trademarks and service marks used herein are the property of their respective owners.
-
Page 12: Right View
Right View MSR Module (Optional) Left View Side USB Ports (x2) Power Switch Copyright © 2023 Fametech Inc. All Rights Reserved. All other brands, product names, company names, trade names, trademarks and service marks used herein are the property of their respective owners. -
Page 13: I/O Ports
I/O Ports Bottom I/O Ports Side I/O Ports Copyright © 2023 Fametech Inc. All Rights Reserved. All other brands, product names, company names, trade names, trademarks and service marks used herein are the property of their respective owners. - Page 14 I/O Ports Descriptions: I/O Port Description MIC-IN 1 x Mic-in for microphone connector LINE-OUT 1 x Line-out for earphone or speaker 3 x COM (RJ45) and 1 x COM (DB9), RI/5V/12V supported COM1~COM3: RJ45 COM5: DB9 female type Connect devices with USB type A connectors USB Ports 4 x USB 3.0 and 2 x USB 2.0 (bottom) 2 x USB 2.0 (side)
-
Page 15: Pos Installation
POS Installation Unpack Your POS The contents may vary with different options. If there’s any physical damage or missing parts, please contact your supplier immediately. Please keep all packing materials in case you need to ship back the device for service. ... -
Page 16: Install Your Pos
Install Your POS The product is a fully integrated POS System and easy for installation. To install the POS System: Place the product on the location. Plug the AC power cord to the POS system. Connect the optional peripherals to the POS (for example, Mouse, Keyboard, and Barcode Scanner.) Plug the AC power cord to the power source (for example, electrical outlet). -
Page 17: Plug Ac Power Cord To The Pos
Plug AC Power Cord to the POS Power Adapter Remove the base cover from the Plug the supplied AC power cord base of the POS System. into the Power Adapter. *The Power Adapter is pre-installed on the bottom of the base (as indicated above). -
Page 18: Install The Rear Top Mount Customer Display (Optional)
Install the Rear Top Mount Customer Display (Optional) Remove the base cover and two hinge covers from the base. There are 2 securing holes for Hinge Cover installing the Customer Display (as indicated below). Hinge Cover Base Cover Securing Tilt the POS unit properly to install Screws... - Page 19 Tilt the customer display properly, andinstall the two hinge covers Hinge Cover onto the base. Re-install the base cover to the Hinge Cover base. Base Cover Tilt the customer display to the angle desired and ready for use. Note: The rear top mount customer display is an Optional Accessory and is not included in the standard package.
-
Page 20: Replace Hard Disk
Replace Hard Disk a. Turn off the POS unit, and unplug the cables from the POS unit. b. Remove the two hinge covers from the base. Copyright © 2023 Fametech Inc. All Rights Reserved. All other brands, product names, company names, trade names, trademarks and service marks used herein are the property of their respective owners. - Page 21 c. Loosen four securing screws on the VESA bracket, and carefully detach the POS unit from the base. d. Carefully place the POS unit to a Securing flat and stable surface (for example, Screw table), and loosen the Securing Screw to remove the HDD Cover.
- Page 22 Hex Spacer HDD Module HDD Cables e. Disconnect the HDD Cables (as arrows indicated), and loosen the Threaded Hex Spacer of HDD Bracket, and remove HDD Module from the POS unit. HDD Bracket f. Loosen the securing screws. ...
