- Page 1 USER MANUAL FXmote V1.0 2024/06/06 Showven Technologies Co., Ltd.
- Page 3 Product Description Δ FXmote is a simple wireless remote specially designed to update for the low quality remote controller we order from market for our series of machine. It is with OLED screen to show the device, effects and battery volume etc, compatible with our YK02 and PROGO remote controller.
- Page 4 Structure of FXbutton Δ 1. ON/OFF Switch 2. Antenna 2 position (reserved) 3. Antenna (when use YK02 mode an antenna need to be installed, when use PROGO mode no need to install antenna) 4. OLED screen 5. Keypad 6. Front panel 7.
- Page 5 1. Button Function Menu: switch through menu items +: Parameter up -: Parameters down Set: match between FXmote and related device Heat: Press heating ON, press and hold for 2s heating OFF Clear: Clear material for SPARKULAR On: Firing ON Off: Firing OFF 2.
- Page 6 I:100.1 H ID:Red ---> First line: FXmote type (YK02 / progo), Send (means sending signal), Battery volume Second line: Device to be controlled Third line: Firing duration (D) and interval (I) Fourth Line: H/L means effect height HIGH/LOW, Wireless ID and firing mode Menu Δ...
- Page 7 Menu Δ...
- Page 8 Press “MENU” to entering firing “interval” setting interface. Interval range from 0.1s-600s. it means the firing interval between adjacent device. Interval 5.0s Set device No. Press “MENU” to entering “device No.” setting interface. Device No. means the devices quantities to be controlled by FXmote, range from 0 to 36units.
- Page 9 “SET” button on FXmote to match the SPARKULAR MOBILE with FXmote. 11. Firing Press any of the “ON” button on FXmote to activate firing. The firing will according to your above settings. SPARKULAR MOBILE will stop working automatically after finish the programmed firing settings.
- Page 10 Press “1ON” button on FXmote to activate firing of SPARKULAR MOBILE with DMX address of 1; Press “2ON” button on FXmote to activate firing of SPARKULAR MOBILE with DMX address of 3; Press “3ON” button on FXmote to activate firing of SPARKULAR MOBILE with DMX address of 5;...
- Page 11 Battery Installation Δ FXmote use 3pcs 23A 12V battery, it is not included in standard configuration, please get it locally. Please check carefully the positive and negative pole of battery, and install battery in the right direction.
- Page 12 Damage caused by external reasons (lightning strike, power supply etc.) Damage caused by improper installation or use; For product damage not included in warranty range, we can provide paid service. Invoice is necessary when applying for maintenance service from SHOWVEN ®...
- Page 13 Showven Technologies Co., Ltd. Tel: +86-731-83833068 Web: www.showven.cn E-mail: info@showven.cn Add: No.1 Tengda Road, Liuyang Economic & Technical Development Zone, 410300, Changsha, Hunan, P.R.China...
