- Page 1 USER MANUAL cFlamer V1.0 2025/03/01 SHOWVEN Technologies Co., Ltd...
- Page 3 Thanks for choosing SHOWVEN cFlamer, we wish it will bring you lots of exciting moments. Please read the following user’s manual and related product installation guide carefully before operating this device. Safety Instructions Δ 1. Safety icons explanation Safety instructions warn of hazards when handling equipment and provide information on how to avoid those hazards.
- Page 4 (no wind, EL nozzle, ISOPAR L and ISOPROPANOL ); Tank Capacity: 5.3L Fuel: SHOWVEN color fluid, ISOPAR L, ISOPROPANOL Color Optional: Red, Gren, Blue, Yellow, Purple (only compatible with SHOWVEN original color fluid) Fuel Tube Filter: Yes Tip sensor: Yes...
- Page 5 Structure Δ 1. Rear panel 2. Top panel 3. Fuel tank cover 4. Fire box 5. Handle 6. Liquid level window 7. Fuel tank cap 8. Fuel tank 9. Igniter 10. Nozzle Diagram of bottom panel...
- Page 6 Rear Panel Δ 1. LCD screen 2. Touch button 3. Safety switch 4. Power Switch (with Power indicator light) 5. Power IN / OUT 6. 3-pin XLR IN/OUT 7. 5-pin XLR IN/OUT (5-PIN XLR IN can charge for wireless DMX pen through pin1 and 4, pin4 with DC5V power supply) 8.
- Page 7 1.) Status Bar : appears when “External Trigger” is “ON” : appears when “safety switch” stay at “USER MODE” 2N/2P/6N: DMX channel mode 2.) Data Bar DMX: DMX address, Background turns from BLACK to RED when DMX cable was connected. SAFE: Safety address, Background turns from BLACK to RED when DMX cable was connected and safety channel activated.
- Page 8 Pressure sensor disconnect / damage please check pressure sensor. E3 Press Sensor Power off machine and let the Pump overload working E4 Pump Protect system cool down, then restart. Main board malfunction Replace main board Machine slant over 45° , it stops Tip setting set to OFF, or E6 Tip Err running.
- Page 9 9. Advanced menu Select “ADVANCED” in menu interface, press “EDIT” enter advanced menu. Use UP / DOWN / SAVE to change the parameters. Default Items Contents Description External Trigger OFF / ON Trigger through 9-60V pyro ignition signal Firing duration under external trigger, this menu appears only when Ext Ignite is ON.
- Page 10 3 different channel mode: 2CH-P, 2CH-N and 6CH-N. 2CH-P(2P): In this channel mode cFlamer occupies 1 functional channel CH-F and 1 separate safety channel CH-S (this channel is independent from operational channel, can be shared with other machine).
- Page 11 Horizontal installation is preferred for cFlamer. If need to install cFlamer in angles, to avoid fake error message please turn the TIP Setting OFF first. cFlamer with maximum tilt angle of 45° or -45° , and it can be angled to two directions as show in below picture. Besides please be aware the fuel...
- Page 12 Fill the fuel tank with qualified color fluid we prepared. To avoid color mix, it is highly recommended to fix the color used on each unit of cFlamer. In case need to change to another color fluid please execute pipeline clean process (refer to 11. Pump and pipeline cleaning of this manual).
- Page 13 If control by DMX controller, follow below steps: Connect a DMX cable to the DMX IN socket of first unit of cFlamer, another head of this DMX cable connect to DMX console (such as FXcommander). Make sure the DMX console is powered off.
- Page 14 Power OFF each unit of machine Unplug power cable, DMX cable, E-Stopper connection cable etc. Pump and pipeline cleaning Collect all cFlamer, take the color fluid tank out and replace with water tank with no less than 2L purified water inside.
- Page 15 WARNING: Pump and pipeline cleaning procedure is a mandatory operation after the machine is used, Not to do so will shorten the shelf life of cFlamer series product due to the corrosive of color fluid. WARNING: Before clean test, make sure there are sufficient purified water in the fuel tank. During the cleaning process, the flamethrower will spray a large amount of water, please ensure there is no non-waterproof objects or equipment around.
- Page 16 2. Nozzle structure and assemble Please assemble the stainless steel gasket, O-ring(blue) and nozzle as shown below. The O-ring should be inside the stainless steel gasket, otherwise it may cause fuel leakage from the nozzle. Please use the nozzle replacement tool hexagon socket wrench to tighten the nozzle. 3.
- Page 17 RMWAS112 O ring (blue), outer 14, wire diameter is 2 mm SFMET1107 G1-E-Stop connector FPEST001 E-STOPPER RMPCK344 Paper carton box for cFlamer FPFLI076 2 in 1 High Quality Flightcase 860* 400* 370mm RMPCK343 Flightcase carton box RMBOT036 Safety loop RMHDT134...
- Page 18 Damage caused by external reasons (lightning strike, power supply etc.) Damage caused by improper installation or use; For product damage not included in warranty range, we can provide paid service. Invoice is necessary when applying for maintenance service from SHOWVEN...
- Page 20 Showven Technologies Co., Ltd. Tel: +86-731-83833068 Web: www.showven.cn E-mail: info@showven.cn Add: No.1 Tengda Road, Liuyang Economic & Technical Development Zone, Changsha, Hunan, 410300, P.R.China...
