4.2.2 Robot End Module

4.2.2.1 End Module Components

Figure 31: References of TM12 / TM12M / TM14 / TM14M / TM16 / TM16M End Module Components

Medium & Heavy Payload Series-Hardware Installation Manual TM12/14/16/20 Series Hardware Version: 3.2 Document Version: 1.01
TECHMAN ROBOT INC.
5F., No. 58-2, Huaya 2nd Rd., Guishan Dist., Taoyuan City, 333411 , Taiwan
TM12 / TM12M / TM14 / TM14M / TM16 / TM16M End Module Components
Analog I/O
Digital I/O
Indication Light Ring
Light module
GRIPPER Button
Camera module
VISION Button
POINT Button
FREE Button
Flange (ISO 9409-1-50-4-M6)
