3. Remove the protective cap from the SFP module, as shown in Figure 21 and
Protective
Figure 21. Removing the protective cap from a wire bale type SFP
Figure 22. Removing the protective cap from a plastic tab type SFP
4. Hold the SFP correctly oriented towards the port as shown in Figure 23 on page
50
SAN04B-R Installation, Service, and User's Guide
Figure 22. Save the cap for future use.
Wire
tab
cap
SFP
module
Protective cap
51 and Figure 24 on page 52. For wire bale type SFPs, make sure the bale is
open, in the unlocked position, as shown in 1 of Figure 23 on page 51). Slide
the SFP into the port until you feel it click into place.
SFP module
