Figure 18. Unlocking the SFP module latch, wire bale type
2. Grasping it by the bale, gently but firmly pull the transceiver out of the port (see
3. Replace the protective cover on the SFP module.
4. Place the SFP module into a static-protective package.
5. If you will not be replacing the SFP, replace the protective cover on the router
Removing a plastic tab type SFP: Follow the steps below to remove a plastic
tab type SFP. (If the SFP is a wire bale type, skip these instructions and follow the
instructions in "Removing a wire bale type SFP" on page 47.)
1. Pull the plastic tab outward 10° from the SFP to unlock it (see Figure 19 on
48
SAN04B-R Installation, Service, and User's Guide
I O
I O
!
I
Open Bale
O I
O I
!
SFP
Bale
2 in Figure 18).
port. If you are replacing the SFP, continue to "Installing an SFP" on page 49.
page 49).
1
2
