FVC SP1127B Installation Manual

Sprinter van front bumper
Hide thumbs

Advertisement

Quick Links

Download this manual
S PRI NTER VAN F R ONT B U MP ER
SP1127 B
INSTALLATION
GUIDE
F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6
TOOLS REQUIRED
+
1/4" RATCHET
+
3/4" SOCKET
+
3/8" RATCHET
+
9/16" SOCKET AND WRENCH
+
T25 TORX
+
7/16" SOCKET AND WRENCH
+
T30 TORX
+
3/8" SOCKET AND WRENCH
+
7/32" ALLEN WRENCH
+
13MM SOCKET
+
5/32" ALLEN WRENCH
+
POWER DRILL
+
AUTO TRIM REMOVAL TOOL
+
BODY SAW
+
SNAP RING PLIERS
+
PAINTERS TAPE
+
SIDE CUTTERS
+
MARKER
+
12" EXTENSION
+
TAPE MEASURE
+
4" EXTENSION
INSTALL INFO
TIME TO INSTALL THIS PRODUCT: 5-6 HOURS
Additional help is suggested for a few of the install steps.
BEFORE YOU START
Please inspect the product and packaging upon
delivery to ensure there are no issues and that
all parts and hardware are accounted for.
Contact us ASAP if anything is missing at:
support@flatlinevanco.com
(NOT INCLUDED)
0 1
