S PRI NTER R EAR DOOR EM B LE M
SP1141 B
INSTALLATION
GUIDE
F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6
TOOLS REQUIRED
(NOT INCLUDED)
+
5/32" ALLEN WRENCH
+
T25 TORX
+
PRY TOOL
INSTALL INFO
TIME TO INSTALL THIS PRODUCT: 15 MINUTES
Additional help is suggested for a few of the install steps.
BEFORE YOU START
Please inspect the product and packaging upon
delivery to ensure there are no issues and that
all parts and hardware are accounted for.
Contact us ASAP if anything is missing at:
support@flatlinevanco.com
0 1
Advertisement
Related Manuals for FVC SP1141B
Summary of Contents for FVC SP1141B
- Page 1 INSTALLATION GUIDE S PRI NTER R EAR DOOR EM B LE M SP1141 B TOOLS REQUIRED (NOT INCLUDED) 5/32” ALLEN WRENCH T25 TORX PRY TOOL INSTALL INFO TIME TO INSTALL THIS PRODUCT: 15 MINUTES Additional help is suggested for a few of the install steps. BEFORE YOU START Please inspect the product and packaging upon delivery to ensure there are no issues and that...
- Page 2 BEFORE YOU START All Flatline Van Co products must be properly assembled and secured before attaching to your vehicle. Improper attachment could result in an automobile accident, and could cause serious bodily injury or death to you or to others involved. You are responsible for assembling and securing Flatline Van Co products to your vehicle, checking the mounting points and attachments prior to use, and regularly inspecting the products for wear and or damage.
- Page 3 PACKAGE CONTENTS SPRINTER REAR DOOR EMBLEM QTY: 1 F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6...
- Page 4 HARDWARE 1/4-20 X 0.5 BUTTON HEAD THREADLOCKER HEX DRIVE SCREW QTY: 2 QTY: 1 F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6...
- Page 5 INSTALL TOOLS REQUIRED FOR THIS STEP: T25 TORX STEP | 01 REMOVE OEM EMBLEM 1.1 Remove Factory Emblem Screws: Use a T25 Torx Wrench to remove the two Screws (FIG 3+4) holding the OEM Mercedes Sprinter Emblem from the Passenger Side Rear Door (FIG 1+2) of your van.
- Page 6 1.2 Remove Factory Emblem: Use a Pry Tool to gently peel the Factory Emblem from any adhesive backing, if applicable (FIG 5+6). NOTE - The contours of the Factory Emblem and the FVC Emblem are the same, but the overall diameter is smaller on the FVC Emblem (FIG 7).
- Page 7 TOOLS REQUIRED FOR THIS STEP: STEP | 02 INSTALL FVC EMBLEM 2.1 Position FVC Emblem: Position the FVC Emblem to the factory holes that held the OEM Emblem in place (FIG 8). 2.2 Thread in Hardware: Apply a small dab of Threadlocker to the supplied 1/4-20 Button Head Screws and thread them in to the FVC Emblem (FIG 9).
- Page 8 FVC (and see) from you! Head to the products and following along and we will make it right. FVC is product page and click “Leave a company of van and outdoor with your adventures. Tag us Review.”...
