S PRI NTER VAN R E AR T IR E CAR RI E R AN D L AD DE R
SP1121 B
INSTALLATION
GUIDE
F L AT L I N E VA N C O • S U P P O R T @ F L AT L I N EVA N C O . C O M • 8 8 8 - 6 6 7- 5 5 7 6
TOOLS REQUIRED
(NOT INCLUDED)
+
13/16" DEEP SOCKET
+
9/16" WRENCH
+
3/16" DRILL BIT
+
3/4" WRENCH
+
1/4" DRILL BIT
+
7/32" ALLEN KEY
+
POWER DRILL
+
5MM ALLEN KEY
+
AUTO PANEL REMOVAL TOOL
+
RATCHET
+
9/16" DEEP SOCKET
INSTALL INFO
TIME TO INSTALL THIS PRODUCT: 1 HOUR
Additional help is suggested for a few of the install
steps.
BEFORE YOU START
Please inspect the product and packaging upon
delivery to ensure there are no issues and that all
parts and hardware are accounted for.
Contact us ASAP if anything is missing at:
support@flatlinevanco.com
0 1
Advertisement
Related Manuals for FVC SP1121B
Summary of Contents for FVC SP1121B
- Page 1 INSTALLATION GUIDE S PRI NTER VAN R E AR T IR E CAR RI E R AN D L AD DE R SP1121 B TOOLS REQUIRED (NOT INCLUDED) 13/16” DEEP SOCKET 9/16” WRENCH 3/16” DRILL BIT 3/4” WRENCH 1/4” DRILL BIT 7/32”...
-
Page 2: Before You Start
BEFORE YOU START All Flatline Van Co products must be properly assembled and secured before attaching to your vehicle. Improper attachment could result in an automobile accident, and could cause serious bodily injury or death to you or to others involved. You are responsible for assembling and securing Flatline Van Co products to your vehicle, checking the mounting points and attachments prior to use, and regularly inspecting the products for wear and or damage. -
Page 3: Package Contents
PACKAGE CONTENTS LOWER HINGE BACKING UPPER HINGE BACKING WHEEL BRACKET DRILL TEMPLATE PLATE PLATE DOOR MOUNTING BOSS QTY: 1 QTY: 1 QTY: 1 QTY: 1 QTY: 1 LOCK ROD BACKER PLATE FOOT PEG BUSHING CAP QTY: 2 QTY: 1 QTY: 2 QTY: 1 FOOR PEG WRENCH TALL BUSHING... - Page 4 HARDWARE 3/8-16 X 3 BUTTON HEAD 3/8 x 1.5 HEX DRIVE 1/2-13 X 1.5 SQUARE NECK HEX DRIVE SCREW BUTTON HEAD SCREW CARRIAGE BOLT 3/8-16 x 1 HEX HEAD SCREW M14-1.5 X 65 WHEEL STUD QTY: 1 QTY: 4 QTY: 4 QTY: 2 QTY: 3 0.787 I.D.SNAP IN PANEL...
- Page 5 INSTALL TOOLS REQUIRED FOR THIS STEP: AUTO PANEL REMOVAL TOOL STEP | 01 LAYOUT AND INSTALL PREP 1.1 Door Panel Removal: If applicable, start by removing the lower interior door panel (FIG 1) and any obstructions in the area shown in FIG 2 (wires, insulation, etc.). We recommend using plastic panel removal tools (easily found at harbor freight or similar).
- Page 6 TOOLS REQUIRED FOR THIS STEP: MARKER 3/16” DRILL BIT 1/4” DRILL BIT 3/8” DRILL BIT STEP BIT STEP | 02 DRILL THIRD MOUNT 2.1 Template Marking: Align the drill template with the van’s body lines and mark the spot as shown in FIG 3 . 2.2 Pilot Hole: Drill a pilot hole through the first layer of metal using a 3/16”...
-
Page 7: Step | 03 Bracket Assembly
3/4” WRENCH OR SOCKET TOOLS REQUIRED FOR THIS STEP: 9/16” WRENCH OR SOCKET STEP | 03 BRACKET ASSEMBLY 3.1 Assemble the Tire Carrier: Attach the Wheel Bracket to the tire carrier frame using: (2) Backer Plates, (4) 1/2-13 X 1.5 Square Neck Carriage Bolts, (4) 1/2 Screw Flat Washers, And (4) 1/2-13 Nylon Insert Locknuts and a 3/4”... - Page 8 TOOLS REQUIRED FOR THIS STEP: STEP | 04 VAN MOUNTS LOWER HINGE UPPER HINGE 4.1 Hinge Backing Plates: Grab both hinge backing plates and (4) 3/8-16 X 1.5 Hex Drive Button Head Screws. Place them into the back of your 180 hinges as shown in FIG 9 and FIG 10. 4.2 Bushing Assembly for Third Mount: Gather 3/8-16 x 3”...
- Page 9 9/16” DEEP SOCKET TOOLS REQUIRED FOR THIS STEP: 9/16” WRENCH 7/32” ALLEN WRENCH *PANEL TRIM SHOWN BACKING PLATE STEP | 05 SECURE CARRIER AND SCREWS 5.1 Third Mount: Holding up the assembled carrier to the door, PANEL PLUG 3/8” WASHER insert the bushing assembly through the third mount hole to center the carrier while you secure it to the hinge mounts in the next step.
- Page 10 TOOLS REQUIRED FOR THIS STEP: 5MM ALLEN WRENCH 13/16” SOCKET STEP | 06 ATTACH WHEEL LOCTITE HERE 6.1 Wheel Studs and Lug Nuts: Apply Loctite to the Wheel Studs on the short end and screw them into the Wheel Bracket. Tighten with a 5mm Allen Wrench (FIG 16).
-
Page 11: Step | 07 Foot Pegs
TOOLS REQUIRED FOR THIS STEP: FOOT PEG WRENCH STEP | 07 FOOT PEGS 7.1 Foot Pegs: Thread on Foot Pegs to locations shown in FIG 18 and use the provided Foot Peg Wrench to tighten foot pegs to carrier (FIG 19). FOOT PEGS F I G 18 F I G 19... - Page 12 FVC (and see) from you! Head to the products and following along and we will make it right. FVC is product page and click “Leave a company of van and outdoor with your adventures. Tag us Review.”...
