COMMISSIONING
information regarding this uplink interface is found in the VACON
that is supplied with the HX-unit.
5.3.2 Application par ameter list
The application parameters and their default values are shown in table 5.3-1. The project specific
parameters are calculated using the rules found in
when setting up the HX-
column. If the values must be changed at a later time the new value should be written in the last
column (Changes, customer). The parameters that must be edited at commissioning are marked
with a *) in the table 5.3-1. More information about these parameters is found in
Parameter description.
Par ameter
code
P2.10.1 *) Frequency to PU11 when PID
enabled
P2.10.2 PT11 pressure transmitter low
pressure setting, scaling
P2.10.3 PT11 pressure transmitter
high pressure setting, scaling
P2.10.4 PT11 pressure error, low
pressure alarm
P2.10.5 Inlet pressure supervision
P2.10.6 FTSA11 temperature
transmitter low temperature
setting, scaling
P2.10.7 FTSA11 temperature
transmitter high temperature
setting, scaling
P2.10.8 *) FTSA11 temperature error,
low temperature alarm
P2.10.9 *) FTSA11 temperature error,
high temperature alarm
P2.10.10 *) FTSA11 temperature error,
high temperature shutoff
P2.10.11 Pump automatic changing
sequence time
P2.10.12 Fault delay setting
P2.11.1 Fieldbus outlet 1
P2.11.2 Fieldbus outlet 2
P2.11.3 Fieldbus outlet 3
P2.11.4 Fieldbus outlet 4
P2.11.5 Fieldbus outlet 5
P2.11.6 Fieldbus outlet 6
P2.11.7 Fieldbus outlet 7
P2.11.8 Fieldbus outlet 7
P3.5 *) FV11 reference temperature
Table 5.3-1, Parameter list
Local contacts: http:/ / dr ives.danfoss.com/ danfoss- dr ives/ local - contacts/
Par ameter descr iption
®
chapters 5.3.6 to 5.3.7. The values that are used
Defaul t Custom,
setting settings
50Hz
0 bar
10 bar
0.5 bar
1
0 C
100 C
22 C
28 C
35 C
169 h
5 s
1501
2
45
1511
1
4
5
37
25
VACON 2 9
chapter 5.3.3,
Changes
(Customer )
