Installing the AXI 22 AT D Plus and WPD 102 XLRM
The AXI 22 AT D Plus and WPD 102 XLRM mount
in a two-gang decorator-style wall plate, which can
be attached to a two-gang mud ring (provided) or a
two-gang wall box (not included).
To mount the products:
1.
Using the mud ring as a guide, mark the edges and
cut out the material within the marked area.
2.
Insert the mud ring into the opening. Rotate and
secure the locking arms with the supplied screws.
3.
Connect the rear panel outputs and inputs, the
Dante-enabled network cable, and power (see
figure 2
on page 2).
4.
Install the devices into the wall box or mud ring and
attach the wall plate. Do not attach the AXI cover
plate at this time.
5.
Connect the front panel inputs.
6.
Connect the front panel outputs.
7.
Start Dante Controller and route the input and
output channels as desired (see
Setup
on page 4 for information on Dante
Controller Software).
8.
Start DSP Configurator and connect to the AXI.
9.
Adjust the gain controls as necessary.
10.
Disconnect the front panel connections, if necessary, and place the cover plate onto the front panel so that the two protruding input
connectors fit through it. Secure the cover plate in place with the provided screw in the center.

Downloading and Installing DSP Configurator Software

The AXI 22 AT D Plus can be controlled with Extron DSP Configurator software using the USB or AT ports, or DataViewer using the USB port.
Install DSP Configurator on a PC running on a PC running Microsoft
DSP Configurator
see the
NOTE:
An Extron Insider account is required to download DSP Configurator.
1. At www.extron.com, hover over the
2.
Click the
DSP Configurator Software
3.
Click the Download
See the DSP Configurator Help File in the software for detailed operating information.
Downloading and Installing Dante Controller Software
Dante Controller from Audinate is required to select and route digital inputs and outputs to connected Dante-compatible devices and for
limited configuration of the device. Install Dante Controller on a PC running Microsoft Windows 10 or newer. For full details about computer
requirements, see the Dante Controller
NOTE: An Extron Insider account is required to download Dante Controller.
1.
At www.extron.com, hover over the
2.
Click the Dante Controller
3.
Click the Download
Dante Network
product page at www.extron.com.
Download tab. The
link. The
button and follow the on-screen instructions to complete the DSP Configurator installation process.
product page at www.extron.com.
Download tab. The
link. The Dante Controller
button and follow the on-screen instructions to complete the Dante Controller installation process.
Wall Mounting
Bracket (Mud Ring)
Figure 4. AXI 22 AT D Plus and WPD 102 XLRM Assembly
Windows 10 or newer. For full details about computer requirements,
® ®
Download
window drops down.
DSP Configurator Software
Download window drops down.
page opens.
Wall
Locking Arm
WPD 102 XLRM
T
P U U T
T P
O U IN
1 1 1
U T
T P
T
O U P U
2
IN
2 2
1
IG
N F
C O
T
P U
IN 1
R
2
T
P U
IN
2
AXI 22 AT D Plus 22 AT D Plus
n
t r o
E x
Cover Plate
page opens.
Wallplate
