Page 3: Parts Ordering
PARTS ORDERING For optional equipment catalogs, please visit https://www.rottlermfg.com/documentation.php For fastest service ordering parts or equipment, contact us via e-mail with the information below. For customers within the U.S., send emails to parts@rottlermfg.com, for customers outside of the U.S., use intlparts@rottlermfg.com Have the following information on hand to expedite the ordering process: 1. -
Page 4: Manual Sections
MANUAL SECTIONS INTRODUCTION INSTALLATION 8029 S 200th Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 010924... - Page 5 READ THE SAFETY CHAPTER BEFORE INSTALLING MACHINE. THOROUGHLY UNDERSTAND ALL SAFETY ISSUES BEFORE OPERATING MACHINE. ATTENTION OWNER/BUSINESS MANAGER To validate the warranty on your new Rottler machine, please be sure to sign and complete the “Installation Report” located in the Installation Chapter of this manual.
-
Page 6: Limited Warranty
Should a product not be as warranted, Rottler sole obligation shall be, at its option, to repair, correct or replace the product or to refund the amounts paid for the Product upon its return to a location designated by Rottler. - Page 7 Section 1: Introduction F69A Installation Manual by Rottler. Rottler shall not be liable for any consequential, direct or indirect damages or for any other injury or loss. Buyer waives any right, beyond the foregoing warranty, to make a claim against Rottler.
-
Page 8: Table Of Contents
Section 2: Installation F69A Installation Manual Section 2 Installation INSTALLATION Contents F69A Installation Report ....................2-2 Machine Dimensions ......................2-8 Front Dimensions ..........................2-8 Side Dimensions ..........................2-9 Clearance Dimensions ........................2-10 Installation Procedure ....................2-11 Location ............................2-11 Unpacking and Lifting ........................2-11 Leveling and Alignment .........................2-13 Leveling Bolt Locations .........................2-14 Air Supply ............................2-15 Power Supply ..........................2-16... - Page 9 Section 2: Installation F69A Installation Manual ATTENTION OWNER/BUSINESS MANAGER To validate the warranty on your new Rottler machine, please be sure to sign the installation report after the installation technician has installed the machine and verified the machine is operating correctly and given the operators operation and maintenance training.
-
Page 10: Installation Report
______Customer has read and fully understands importance of machine location as explained in the installation section of the manual. Customer responsibility prior to the arrival of Rottler Sales/Service technician. Please Initial each item when it is completed. ______Remove machine from truck. - Page 11 ______Place a thin film of silicone on one side of the ball screw caps and install them in place of both the X and Y axis locks. Rottler Technician Installation checklist ______BEFORE turning power on to the machine: Check all wires for security by gently tugging on the wires and then use the correct screw driver, turning CW until movement stops.
- Page 12 The software on the machine will automatically connect to our server to send back useful information on machine status. ______Explain to the customer and the operator how the to log onto Skype and communicate with Rottler when needed.
- Page 13 MACHINE MOVEMENTS Note: Rotter employees and representatives per company policy are not permitted to provide end user of Rottler equipment with any OEM specifications for the workpiece that is created by end user using Rottler equipment. ______Make sure there is nothing obstructing the full vertical or horizontal travel of the machine taking special notice of the rear enclosure, way travel and top of the spindle unit.
- Page 14 Rottler equipment. It is the responsibility of the end user of Rottler equipment to determine the final dimensions and finishes of the workpiece that they are working on. Any information regarding final dimensions and...
- Page 15 Section 2: Installation F69A Installation Manual ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ ___________________________________________________________________________________ Instructions given to:___________________________________________________________________ Sales/Service Technician: ____________________________________________ Date_____________ Shop Foreman/Superintendent or Owner: ________________________________ Date_____________ Once completed e-mail this form to: service@rottlermfg.com 8029 S 200th Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 010924...
-
Page 16: Machine Dimensions
Section 2: Installation F69A Installation Manual Machine Dimensions Side Dimensions 8029 S 200th Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 010924... -
Page 17: Clearance Dimensions
Section 2: Installation 2-10 F69A Installation Manual Clearance Dimensions 8029 S 200th Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 010924... - Page 18 Section 2: Installation 2-11 F69A Installation Manual 8029 S 200th Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 010924...
-
Page 19: Installation Procedure
Section 2: Installation 2-12 F69A Installation Manual Installation Procedure Placement of Machine IMPORTANT! It is critical that the machine be placed in an area of the facility that has a stable thermal environment. The machine should be kept away from direct sunlight, large heating units, and doorways that would allow outside air direct contact on the machine. - Page 20 Section 2: Installation 2-13 F69A Installation Manual Be sure that the forks are at least Four inches through the opposite side of the casting. This machine is extremely top heavy. Use extreme care whenever this machine is being used. Do not use quick or sharp movement. Type Two Remove the Toolbox, Parallels and optional equipment form the machine.
-
Page 21: Leveling And Alignment
Leveling and Alignment Leveling the F69A properly is very important if you are to use the F69A to its full blue printing capabilities as well as maximizing the use of Rottler fixturing. Use the following instructions to properly level the F69A. -
Page 22: Air Supply
Section 2: Installation 2-15 F69A Installation Manual Air Supply It is very important that the air source for the F69A be moisture free. Water and oil in the air lines will result in early cylinder and valve failure as well as introducing moisture into the Inner spindle bearings. The factory recommends installing a water trap at the machine. - Page 23 Section 2: Installation 2-16 F69A Installation Manual 8029 S 200th Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 010924...
-
Page 24: Power Supply
Section 2: Installation 2-17 F69A Installation Manual Power Supply This machine has the following power requirements: • 208 to 240 VAC • Single Phase • 50 or 60 Hertz • 30 amps See illustration below for correct connection of incoming power. Measured power at the machine’s main breaker must be within the required range listed above. -
Page 25: Grounding
Note: The Rottler F69A uses a touch screen for control and data transfer to the computer. Be careful not to touch the screen until the machine has fully booted up and a Rottler screen is showing. If the screen is touched prior to full boot –up it may activate a function or interfere with proper boot-up. - Page 26 F69A Installation Manual Click on the New button to view all of the available modes. This will take you to the Rottler program where the handwheel can be used. Highlight the Cylinder Bore mode and touch the OK button. This will bring up the Operation screen.
