Page 3: Parts Ordering
PARTS ORDERING For optional equipment catalogs, please visit https://www.rottlermfg.com/documentation.php For fastest service ordering parts or equipment, contact us via e-mail with the information below. For customers within the U.S., send emails to parts@rottlermfg.com, for customers outside of the U.S., use intlparts@rottlermfg.com Have the following information on hand to expedite the ordering process: 1. -
Page 4: Manual Sections
MANUAL SECTIONS INTRODUCTION MAINTENANCE TROUBLESHOOTING MACHINE PARTS 8029 S 200 Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 020122... -
Page 5: Table Of Contents
Section 1 Introduction S85A / S86A Manual INTRODUCTION Contents Introduction ........................ 1-1 Description ......................... 1-2 Disclaimer ........................1-2 Limited Warranty ......................1-3 Online Documentation Access ................. 1-4 8029 S 200 Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230... -
Page 6: Introduction
“Installation Report” located in the Installation Chapter of this manual. We suggest that the new user of the S85A / S86A read the CONTROL DEFINITIONS to get an idea how the machine operates. -
Page 7: Description
90 and 60 degree V-type blocks as well as cylinder heads. S85A / S86A machines may be readily tooled to resurface a wide variety of engines, including European and Asian models, as well as perform various other surfacing operations. -
Page 8: Limited Warranty
Should a product not be as warranted, Rottler sole obligation shall be, at its option, to repair, correct or replace the product or to refund the amounts paid for the Product upon its return to a location designated by Rottler. -
Page 9: Online Documentation Access
S85A / S86A Manual Online Documentation Access Online documentation for machines and optional equipment can be accessed at the Rottler website. To access documentation open your browser and navigate to https://www.rottlermfg.com. Scroll to the bottom of the page and under the Owner Resources title click the type of documentation you want to access. - Page 10 Section 1 Introduction S85A / S86A Manual 8029 S 200 Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 020122...
- Page 11 Horizontal Ballscrew Nut ................2-14 Vertical Ballscrew Nut ..................2-18 Lubrication Quick Reference Guide ............... 2-18 S85A/S86A Machine Lubrication Illustrations ..........2-18 2-Axis Universal Machine Table Lubrication Illustration ......2-18 Setting Cutting Tool Inserts ................. 2-19 Production Cutting ..................2-19 Aluminum and Cast Iron .................
-
Page 12: Maintenance
Lubrication Refer to the illustrations on the following pages for locations and the chart below for lubrication intervals. For ease of access to the grease fittings, an extension adapter is recommended. Rottler recommends the Lincoln Model 5855 Extension Adapter. All linear bearings on Rottler Surfacing machines are equipped with the latest sealing and lubrication technologies available, ensuring long life and low maintenance requirements. -
Page 13: S85A/S86A Machine Lubrication Illustrations
Section 2: Maintenance S80 Maintenance and Parts Manual S85A / S86A Machine Lubrication Illustration 8029 S 200 Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 020122... -
Page 14: 2-Axis Universal Machine Table Lubrication Illustration
Section 2: Maintenance S80 Maintenance and Parts Manual 2 Axis Universal Machine Table 7119Q – Lubrication Illustration 8029 S 200 Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 020122... -
Page 15: Setting Cutting Tool Inserts
Section 2: Maintenance S80 Maintenance and Parts Manual Setting Cutting Tool Inserts Travel the spindle base approximately to the center of the main base. Turn off all power to machine before proceeding. Remove cutterhead and chip shield. Replace cutterhead without chip shield. Attach a dial runout indicator to a cylinder head or engine block, etc. -
Page 16: Dial Indicator Setting
Section 2: Maintenance S80 Maintenance and Parts Manual Dial Indicator Setting If chip shield, cutting insert, or dial indicator have been moved, the dial indicator should be reset. With the surfacing cutter in the fore and aft position, press the left travel button until the cutterhead overlaps a test piece by about 1/2”... -
Page 17: Drive Sprocket / Motor Removal And Replacement
Section 2: Maintenance S80 Maintenance and Parts Manual Drive Sprocket / Motor Removal and Replacement Turn off all power to the machine before continuing. 1. Remove spindle/motor access cover by releasing cover latch. 2. Open and raise cover to remove. 3. -
Page 18: Cutterhead And Chip Guard Removal
Section 2: Maintenance S80 Maintenance and Parts Manual Cutterhead and Chip Guard Removal Turn off all power to the machine before continuing. 1. Mark cutterhead and spindle so they can be reassembled in the same position. 2. Remove cutterhead by removing the 4 screws holding it in place. 3. - Page 19 Section 2: Maintenance S80 Maintenance and Parts Manual 8029 S 200 Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 020122...
-
Page 20: Horizontal Ballscrew Removal And Replacement
Section 2: Maintenance 2-10 S80 Maintenance and Parts Manual Horizontal Ballscrew Removal and Replacement Move the carriage to the center of the machine and press the E-Stop button. Disconnect all power to the machine before continuing Do the following procedure while at the back of the machine. 1. - Page 21 Section 2: Maintenance 2-11 S80 Maintenance and Parts Manual 2. Remove the 4 SHCS holding the support bearing (7313) 3. Remove the 5 SHCS on the ballscrew nut (7313A) 4. Remove ballscrew support (7303A) 5. Remove ballscrew from machine 8029 S 200 Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230...
- Page 22 Section 2: Maintenance 2-12 S80 Maintenance and Parts Manual 6. With ballscrew held in a vice with soft jaws, remove the coupler (7316A), lock nut (6777C), and bearing (7313) Note: Be sure when removing the bearing, that the inner race does not come apart. 7.
-
Page 23: Vertical Ballscrew Removal And Replacement
Section 2: Maintenance 2-13 S80 Maintenance and Parts Manual Vertical Ballscrew Removal and Replacement Move the horizontal carriage to the center of the machine. Move the vertical carriage to the top of its travel. Place a block of wood under the chip shield as shown to support the carriage when the ballscrew is removed. - Page 24 Section 2: Maintenance 2-14 S80 Maintenance and Parts Manual Remove the 5 SHCS that hold the ballscrew nut to the carriage. The carriage will drop down until the chip shield makes contact with the wood block that was placed under it. Remove the 2 wires connected to the ballscrew motor and then remove the 4 SHCS that hold the motor and brake assembly to the ballscrew housing.
- Page 25 Section 2: Maintenance 2-15 S80 Maintenance and Parts Manual Remove the ballscrew assembly from the machine. With ballscrew held in a vice with soft jaws, remove 4 SHCS holding the bearing assembly to the housing, then remove the coupler, lock nut, and bearing. Note: Be sure when removing the bearing, that the inner race does not come apart.
- Page 26 Section 2: Maintenance 2-16 S80 Maintenance and Parts Manual Replace motor and cables. Turn on power to machine and release the E-Stop. Home machine. Remove block of wood. Run horizontal carriage to the center of the bed. Run vertical carriage down to bottom of travel. Tighten 5 SHCS holding ballscrew nut to carriage.
-
Page 27: Troubleshooting
Rottler Factory Service at service@rottlermfg.com for assistance and your service request. You may also call Rottler at 1-800-452-0534 or 1-253-872-7050 Please ensure you have the Machine Model and Serial Number available when contacting Rottler for Service... -
Page 28: Machine Parts
Section 4: Machine parts S80 Maintenance and Parts Manual MACHINE PARTS Contents Machine Parts ......................8 1 Base Assembly Parts ......................8 1 7326 Chip Curtains ....................... 8 2 Control Panel Assembly Parts .................... 8 3 Electrical Enclosure Parts ....................8 4 Electrical Panel Parts ...................... -
Page 29: Base Assembly Parts
Section 4: Machine parts S80 Maintenance and Parts Manual Machine Parts Base Assembly Parts ITEM PART NUMBER DESCRIPTION MF-2 S.H.C.S. #8-32 X ½” LINEAR RAIL CAR 7341D RAIL ASSEMBLY, X-AXIS, ROLLER LINEAR – S86 7314F RAIL ASSEMBLY, X-AXIS, ROLLER LINEAR – S85 MF-15A S.H.C.S. -
Page 30: 7326 Chip Curtains
Section 4: Machine parts S80 Maintenance and Parts Manual ITEM PART NUMBER DESCRIPTION 7170 SOCKET SET SCREW, ¾-10 X 4”, SQUARE HEAD 502-1-12F NUT, JAM, ¾-10 7300G PAD, LEVELING 7326 Chip Curtains Sold only as complete Assemblies. Service parts not available. One each, machine uses 2 assemblies. -
Page 31: Control Panel Assembly Parts
Section 4: Machine parts S80 Maintenance and Parts Manual Control Panel Assembly Parts ITEM PART NUMBER DESCRIPTION 514-13-99A 10” TOUCH SCREEN DISPLAY 7328E ENCLOSURE, PENDANT 7328D BRACKET, PENDANT ANGLE MF-90 B.H.C.S. ¼-20 X ½” 514-13-22G PLATE, CONTROL PANEL MF-89B B.H.C.S. #10-32 X ½” 6389D PUSHBUTTON, EMERGENCY STOP 8029 S 200... -
Page 32: Electrical Enclosure Parts
Section 4: Machine parts S80 Maintenance and Parts Manual Electrical Enclosure Parts ITEM PART NUMBER DESCRIPTION 514-7-48B COVER, ELECTRICAL ENCLOSURE DOOR FILTER 514-7-48C FILTER, DOOR 9030E DOOR LATCH – ELECTRICAL ENCLOSURE 9035G CIRCUIT BREAKER – 30 AMP – MAIN POWER 514-7-47R TOP PANEL 514-7-47U... - Page 33 Section 4: Machine parts S80 Maintenance and Parts Manual ITEM PART NUMBER DESCRIPTION 514-7-47R TOP PANEL 514-7-47U RIGHT SIDE PANEL 9030T BRACKET, SWITCH – ELECTRICAL 514-7-47T LEFT SIDE PANEL 7560 POWER SUPPLY, 36V 514-7-47S BOTTOM PANEL 8029 S 200 Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 020122...
-
Page 34: Electrical Panel Parts
Section 4: Machine parts S80 Maintenance and Parts Manual Electrical Panel Parts ITEM PART NUMBER DESCRIPTION 502-36-48C VECTOR DRIVE – 2 HP, 1 PHASE, 240V 6554L DUCT, WIRING (1 ½” X 2”) 7.25” 514-7-48E PANEL, ELECTRICAL ENCLOSURE, BACK 502-36-42H REACTOR, LINE (CHOKE) AC FREQUENCY INVERTER 504-35-3M CAP, DIN RAIL 514-7-74C... -
Page 35: Machine Enclosure Base Parts
Section 4: Machine parts S80 Maintenance and Parts Manual Machine Enclosure Base Parts ITEM PART NUMBER DESCRIPTION 7327B LEFT SIDE SUPPORT 7327A RIGHT SIDE SUPPORT 7323A DOOR SILL, S85 7323H DOOR SILL, S86 Machine Enclosure Door Parts ITEM PART NUMBER DESCRIPTION 7323D DOOR, UPPER –... -
Page 36: Machine Enclosure Surround Parts
Section 4: Machine parts S80 Maintenance and Parts Manual Machine Enclosure Surround Parts ITEM PART NUMBER DESCRIPTION 7320D GUSSET 7320E REAR PANEL, S86 7320R REAR PANEL, S85 7320N REAR REMOVABLE PANEL 7320E REAR PANEL, S86 7320R REAR PANEL, S85 7328A SIDE PANEL 7328B FRONT, RIGHT SIDE PANEL... -
Page 37: Spindle Assembly Parts
Section 4: Machine parts S80 Maintenance and Parts Manual Spindle Assembly Parts ITEM PART NUMBER DESCRIPTION 7304B MOUNT, MOTOR SPINDLE 7306F HOUSING, SPINDLE 507-6-3G MOTOR MF-32 S.H.C.S. ⅜-16 X 1 ¼” 7326A COVER, BELLOWS, Z-AXIS 8029 S 200 Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 020122... - Page 38 Section 4: Machine parts 4-10 S80 Maintenance and Parts Manual ITEM PART NUMBER DESCRIPTION MF-11 S.H.C.S. ¼-20 X ⅜” MF-88 B.H.C.S. #10-24 X ⅜” 7304Q COVER, BALLSCREW, FRONT 7316E BELT, SPINDLE DRIVE F.H.C.S. ⅜-16 X 1” 7316D SPROCKET, DRIVE & DRIVEN H.H.C.S.
-
Page 39: Spindle Cover Parts
Section 4: Machine parts 4-11 S80 Maintenance and Parts Manual Spindle Cover Parts ITEM PART NUMBER DESCRIPTION 7304M COVER, FRONT, SPINDLE HOUSING 7304P COVER, REAR, SPINDLE HOUSING 7304K LATCH, DOOR ITEM PART NUMBER DESCRIPTION MF-88 B.H.C.S. #10-24 X ⅜” MF-186D NYLOCK NUTS #8-32 504-34-76E HINGE, COVER... -
Page 40: Tower Assembly Parts
Section 4: Machine parts 4-12 S80 Maintenance and Parts Manual Tower Assembly Parts ITEM PART NUMBER DESCRIPTION 7319D CHAIN, Z-AXIS CABLE 7314 Z-AXIS LINEAR RAIL CAR (SOLD WITH 7314E ASS’Y) 7314E RAIL ASSEMBLY, Z-AXIS ROLLER LINEAR MF-15A S.H.C.S. ¼-20 X 7/8” 7314A CLMAP, LINEAR RAIL MF-2... - Page 41 Section 4: Machine parts 4-13 S80 Maintenance and Parts Manual ITEM PART NUMBER DESCRIPTION 7301H TOWER 7319C CHAIN, X-AXIS CABLE – S86 7319E CARRIER, CABLE X-AXIS – S85 MF-5A S.H.C.S. #10-24 X ½” 7302A BAR, FRONT GUIDE MF-13 S.H.C.S. ¼-20 X ⅝” 8029 S 200 Street, Kent, WA 98032 USA | www.rottlermfg.com...
-
Page 42: X-Axis Ballscrew Assembly Parts
Section 4: Machine parts 4-14 S80 Maintenance and Parts Manual X-Axis Ballscrew Assembly Parts ITEM PART NUMBER DESCRIPTION 6778C BEARING 7306C RING, SNAP 7303A MOUNT, X-AXIS SUPPORT BEARING MF-28E S.H.C.S. 5/16-18 X 3” 7313D BALL SCREW ASSEMBYL, X-AXIS – S86 7313H BALL SCREW ASSEMBLY, X-AXIS –... -
Page 43: Z-Axis Ballscrew Assembly Parts
Section 4: Machine parts 4-15 S80 Maintenance and Parts Manual ITEM PART NUMBER DESCRIPTION 7318 MOTOR MF-28E S.H.C.S. 5/16-18 X 3” 7303 MOUNT, X-AXIS BEARING MOTOR S.H.C.S. #10-24 X 1 ⅜” 7313 BEARING, BALLSCREW SUPPORT 6777C NUT, LOCK 7316A COUPLING, X-AXIS MOTOR DRIVE MF-5A S.H.C.S. - Page 44 Section 4: Machine parts 4-16 S80 Maintenance and Parts Manual ITEM PART NUMBER DESCRIPTION 7318 MOTOR 7318A BRAKE, Z-AXIS MOTOR 7316A COUPLING, Z-AXIS MOTOR DRIVE 6777C NUT, LOCK S.H.C.S. #10-24 X 1 ⅜” 7313 BEARING, BALLSCREW SUPPORT MF-15 S.H.C.S. ¼-20 X 1” 7313B MOUNT, Z-AXIS MOTOR MF-5...
- Page 45 Section 5: Safety Data Sheet S80 Maintenance and Parts Manual 8029 S 200 Street, Kent, WA 98032 USA | www.rottlermfg.com | Ph: (253) 872-7050 | Fax: (253) 393-0230 Rev 100720...
- Page 46 Other substances and materials are used in the manufacture, testing, and shipping of this machine. A complete list of the Safety Data Sheets of substances and materials used by Rottler Manufacturing during manufacturing, testing, and shipping is located on the Manual flash drive shipped with the machine.
-
Page 47: Hazard(S) Identification
Section 5: Safety Data Sheet S80 Maintenance and Parts Manual SAFETY DATA SHEET 1. Identification Product Identifier NAPA® White Lithium Grease Other Means of Identification Product Code No. 095037 (Item# 1008003) Recommended Use Lubricating grease Recommended Restrictions None known Manufacturer/Importer/Supplier/Distributor Information Manufactured or Sold by: Company Name CRC Industries, Inc. -
Page 48: Composition/Information On Ingredients
Section 5: Safety Data Sheet S80 Maintenance and Parts Manual accumulate readily and may ignite. Use only with adequate ventilation; maintain ventilation during use and until all vapors are gone. Open doors and windows or use other means to ensure a fresh air supply during use and while product is drying. -
Page 49: Fire-Fighting Measures
Section 5: Safety Data Sheet S80 Maintenance and Parts Manual Most Important Aspiration may cause pulmonary edema and pneumonitis. May cause drowsiness and symptoms/effects, acute and dizziness. Headache. Nausea, vomiting. Irritation of eyes. Exposed individuals may delayed experience eye tearing, redness, and discomfort. Skin irritation. May cause redness and pain. -
Page 50: Handling And Storage
Section 5: Safety Data Sheet S80 Maintenance and Parts Manual Environmental precautions Avoid release to the environment. Inform appropriate managerial or supervisory personnel of all environmental releases. Prevent further leakage or spillage if safe to do so. Avoid discharge into drains, water courses, or onto the ground. Use appropriate containment to avoid environmental contamination. - Page 51 Section 5: Safety Data Sheet S80 Maintenance and Parts Manual Components Type Value Form 2,2-dimethylbutane (CAS 75-83-2) STEL 1000 ppm 2,3-dimethylbutane (CAS 72-29-8) 500 ppm STEL 1000 ppm 2-methylpentane (CAS 107-83-5) 500 ppm STEL 1000 ppm 3-methylpentane (CAS 96-14-0) 500 ppm STEL 1000 ppm Distillates (petroleum), hydrotreated...
-
Page 52: Physical And Chemical Properties
Section 5: Safety Data Sheet S80 Maintenance and Parts Manual Naphtha (petroleum), hydrotreated 400 mg/m3 light (CAS 64742-49-0) n-hexane (CAS 110-54-3) 100 ppm 180 mg/m3 50 ppm Zinc oxide (CAS 1314-13-2) Ceiling 15 mg/m3 Dust STEL 10 mg/m3 Fume 5 mg/m3 Fume 5 mg/m3 Dust... -
Page 53: Stability And Reactivity
Section 5: Safety Data Sheet S80 Maintenance and Parts Manual Flash Point < 0°F (-17.8°C) Tag Closed Cup Evaporation Rate Fast Flammability (solid, gas) Not available Upper/lower Flammability or explosive limits Flammability limit – lower (%) 1% estimated Flammability limit – upper (%) 8% estimated Vapor Pressure 2377.8 hPa estimated... -
Page 54: Ecological Information
Section 5: Safety Data Sheet S80 Maintenance and Parts Manual Oral LD50 >5000 mg/kg naphtha (petroleum), hydrotreated light (CAS 64742-49-0) Acute Dermal LD50 Rabbit >2000 mg/kg n-hexane (CAS 110-54-3) Acute Dermal LD50 Rabbit >1300 mg/kg Oral LD50 15840 mg/kg zinc oxide (CAS 1314-13-2) Acute Oral LD50... -
Page 55: Disposal Considerations
Section 5: Safety Data Sheet S80 Maintenance and Parts Manual Fish LC50 Rainbow trout, Donaldson trout 5000 mg/L, 96 hours (Oncorhynchus mykiss) naphtha (petroleum), hydrotreated light (CAS 64742-49-0) Aquatic Acute Crustacea EC50 Daphina 1-10 mg/L, 48 hours Fish LC50 Fish 1-10 mg/L, 96 hours n-hexane (CAS 110-54-3) Aquatic... -
Page 56: Regulatory Information
Section 5: Safety Data Sheet S80 Maintenance and Parts Manual Transport hazard class(es) Class Subsidiary risk Label(s) Packing group Not applicable Special precautions for user Read safety instructions, SDS and emergency procedures before handling Special provisions Packaging exceptions Packaging non bulk None Packaging bulk None... - Page 57 Section 5: Safety Data Sheet S80 Maintenance and Parts Manual Superfund Amendments and Reauthorization Act of 1986 (SARA) Section 311/312 Hazard categories Immediate Hazard – Yes Delayed Hazard – Yes Fire Hazard – Yes Pressure Hazard – Yes Reactivity Hazard – No SARA 302 Extremely Hazardous Substance US State Regulations US California.
- Page 58 Section 5: Safety Data Sheet S80 Maintenance and Parts Manual International Inventories Country(s) or region Inventory Name On Inventory (yes/no)* Australia Australian Inventory of Chemical Substances (AICS) Canada Domestic Substances List (DSL) Canada Non-Domestic Substances List (NDSL) China Inventory of Existing Chemical Substances in China (IECSC) Europe European Inventory of Existing Commercial Chemical Substances (EINECS)
