PROTECT

PROTECT MENU
POWER SAVE SETTINGS*
POWER SAVE
TIME SETTING
MODE
USB
USB POWER
POWER SAVE MESSAGE
QUICK START
THERMAL MANAGEMENT
FAN CONTROL
FAN SPEED
DISPLAY
INTERNAL TEMPERATURE
SLOT
FAN STATUS
INTERNAL TEMPERATURE
SYSTEM FAN
REQUIREMENT
OPTION
COMPUTE MODULE
1
Enables or disables the monitor entering power saving mode.
When [ENABLE] is selected, the monitor goes into power saving mode after the period of time has passed
with no input signal detected or signal loss has occurred.
You can set the power saving condition in [MODE].
When the monitor is in power saving mode, the LED power indicator will change color. Refer to the Power
indicator table (see page
When [DISABLE] is selected, the monitor doesn't go into power saving mode.
The monitor will enter the state selected for [MODE] in the following condition:
The monitor is powered off by pressing the main power switch or POWER ON button on the remote
control, [POWER] in [SCHEDULE INFORMATION], or by an external control.
Please refer to the monitor's specifications (see
"M551-2" on page 70
NOTE: • When the monitor is connected to a computer, the computer's display adapter may not stop


sending digital data even though there is no image on-screen. If this occurs the monitor will
not switch into standby mode.

• The [POWER SAVE] function is disabled when [AUTO OFF] is turned on in the SCHEDULE
menu, or when [HUMAN SENSING]*
CONTROL menu.

* : The function is available only when connecting the optional sensor unit.
1
Sets the amount of time the monitor should wait for input signal before going into power save mode.
When [LOW POWER] is selected, the monitor cannot detect an input signal from the connected device will
not turn on automatically. To turn on the monitor, please press the main power switch on the monitor or the
POWER ON button on the remote control, or disconnect and reconnect the device's signal cable.
When [NORMAL] is selected, the monitor turns on by detecting an input signal from a connected device.
Please set to [NORMAL] when using an external control function (see
[ON] allows power supply to USB port when the monitor is in standby mode.
NOTE: Power consumption by devices connected to this port depends on the USB devices.


Shows a message as the monitor is entering low power mode.
When [ENABLE] is selected, the monitor will quickly return to the [ON] state when a signal is detected.
Enabling this option increases standby power consumption.
When [AUTO] is selected, the fans will only turn on when the internal temperature reaches the
temperature set at any one of the sensors in this menu. The fans will automatically turn off when the
monitor is cooler. When [ON] is selected the fans are always on. The fans cannot be turned off manually.
The cooling fan starts when the internal temperature exceeds the temperature set or when [FAN
CONTROL] is set to [ON].
The [FAN SPEED] can be adjusted [LOW] or [HIGH].
Shows the status of the the internal temperature of the monitor.
Shows the internal temperature of the monitor.
Shows the internal temperature of the Option Board.
Shows the status of the monitor's internal fan.
Shows the internal temperature of the Option Board.
Show the requirement operation from the Option Board and Compute Module.
65).
"M431-2" on page
and "M651-2" on page 71) for power consumption information.
1
English−86
68, "M501-2" on page
is enabled in the [AUTO DIMMING] section of the
page 51).
69,
