SYSTEM MENU
OSD
OSD TIME*
1
OSD POSITION*
1
OSD SIZE*
1
INFORMATION OSD*
1
COMMUNICATION INFO.*
OSD ROTATION
LANDSCAPE
PORTRAIT
KEY GUIDE*
1
CLONE SETTING*
1
ALL INPUT
INPUT
AUDIO
SCHEDULE
NETWORK
PROTECT
SYSTEM
HTTP
COPY START - USB READ
COPY START - USB WRITE
POWER INDICATOR
MUTE SETTING*
1
UPDATE FIRMWARE*
1
RESET
FACTORY RESET*
1
RESET
* : This option is shown and enables for setting only when [LANDSCAPE] is set to [OSD ROTATION].
1
Turns off the OSD after a period of inactivity. The preset choices are 10-240 seconds.
Determines the location where the OSD appears on the screen.
Change the size of the OSD on the screen.
Selects whether or not to automatically show information about the monitor when it powers on, changes
input, or the current input signal changes.
The information includes the current input, audio source, aspect ratio, resolution, and refresh rate.
The monitor's ID and IP address are also shown unless their setting is OFF.
Note that the information OSD is also displayed when pressing the DISPLAY button on the remote control.
The remote control function cannot be turned off.
Selects whether or not to show the [IP ADDRESS] when the [INFORMATION OSD] is [ON].
1
The information is set in [NETWORK INFORMATION] at [NETWORK].
Changes the OSD orientation between landscape and portrait.
NOTE: OSD settings in [LANDSCAPE] mode are kept in [PORTRAIT] mode.


Shows the OSD in landscape orientation.
Shows the OSD in portrait orientation.
Shows the monitor's button controls Key Guide when opening the OSD Menu.
The Key Guide is aligned to the monitor's button control panel and does not move if the OSD POSITION
changes. It is a visual guide to indicate the position of the buttons so that features can be easily adjusted
when not using a remote control.
Allows for exporting and importing some of the OSD menu settings between monitors. The settings
are saved on a USB storage device (formatted FAT16 or FAT32) connected to the monitor's USB port
(See page 31).
Select to import the settings for all input terminals. If this option is not selected, the settings are only
imported for the current input terminal.
Individually select each OSD menu function's settings to import.
NOTE: The selection of which settings to copy is reset to default if the monitor's main power is turned off.


The [HTTP] option is for copying the monitor's web interface settings. Only settings that are not
monitor specific are exported and imported during this process.
Imports the monitor settings from a connected USB storage device.
Exports the monitor settings to a connected USB storage device.
Turns on or off the LED that indicates the monitor is powered on and in active mode. The monitor's power
LED will not glow when this setting is [OFF].
Allows you to mute the monitor's audio and video output.
AUDIO: Mutes the audio output when the remote control's MUTE button is pressed.
VIDEO: Mutes the video output when the remote control's MUTE button is pressed.
AUDIO & VIDEO: Mutes the audio and video output when the remote control's MUTE button is pressed.
NOTE: The MUTE setting is released in the following cases:



• If you change the [INPUT], turn off/on the main power switch, turn off/on with the ⏻ button on
the remote control or the main unit, return from power save, change the [MUTE SETTING],
change the [AUDIO MODE], when the volume is changed with the remote control or the main
unit key, or when the video signal (resolution/scanning frequency) is changed.
Updates the firmware by connecting the USB storage device (FAT16, FAT32) that stores the FIRMWARE
image file (PAC file) to the monitor.
Resets all system menu settings back to factory setting, except for [LANGUAGE], [OSD ROTATION],
[KEY GUIDE] and [DATE & TIME].
All items are returned to factory shipment state.
