PROTECT

PROTECT MENU
POWER SAVE SETTINGS
POWER SAVE
TIME SETTING
POWER SAVE MESSAGE
QUICK START
THERMAL MANAGEMENT
FAN CONTROL
FAN SPEED
DISPLAY
FAN STATUS
INTERNAL
TEMPERATURE
SLOT
FAN STATUS
INTERNAL
TEMPERATURE
SYSTEM FAN
REQUIREMENT
OPTION
COMPUTE MODULE
Enables or disables the monitor entering power saving mode. When [ENABLE] is selected, the monitor
goes into power saving mode after the period of time has passed with no input signal detected or signal
loss has occurred. When the monitor is in power saving mode, the LED power indicator will change color.
Refer to the Power indicator table (see
into power saving mode.
Please refer to the monitor's specifications (see
NOTE: • When the monitor is connected to a computer, the computer's display adapter may not stop


sending digital data even though there is no image on-screen. If this occurs the monitor will
not switch into standby mode.

• If [AUTO OFF] or [CUSTOM] is selected in [HUMAN SENSING]*
does not work.

* : This function is available only when connecting the optional sensor unit.
1
Sets the amount of time the monitor should wait for input signal before going into power save mode.
Shows a message as the monitor is entering low power mode.
When [ENABLE] is selected, the monitor will quickly return to the [ON] state when a signal is detected.
Enabling this option increases standby power consumption.
Sets the cooling fan behavior.
[AUTO] to protect the internal components, the fan turns on when the monitor's internal temperature
exceeds operating parameters. The fans will automatically turn off when the monitor's internal temperature
is within its normal operating specifications.
[ON] the monitor's fan is always on.
NOTE: The fan cannot be manually controlled. It is always on when [ON] is selected in the OSD menu or


when [AUTO] is selected and the monitor's internal temperature exceeds its specified operating
temperatures.
The [FAN SPEED] can be adjusted between LOW and HIGH.
Shows the status of the monitor's internal fan.
Shows the status of the internal temperature of the monitor.
Shows the internal temperature of the Option Board.
Shows the status of the fan for the Option Board.
Shows the status of the internal temperature of the Option Board.
Show the requirement operation from the Option Board.
page 78). When [DISABLE] is selected, the monitor doesn't go
"M981" on page
English−101
81) for power consumption information.
, the power save function
