PROTECT

PROTECT MENU
POWER SAVE SETTINGS
POWER SAVE
TIME SETTING
MODE
USB
USB POWER
POWER SAVE MESSAGE
QUICK START
THERMAL MANAGEMENT
FAN CONTROL
FAN SPEED
DISPLAY
FAN STATUS
INTERNAL
TEMPERATURE
SLOT
FAN STATUS
INTERNAL
TEMPERATURE
SYSTEM FAN
REQUIREMENT
OPTION
COMPUTE MODULE
Enables or disables the monitor entering power saving mode.
When [ENABLE] is selected, the monitor goes into power saving mode after the period of time has passed
with no input signal detected or signal loss has occurred.
You can set the power saving condition in [MODE].
When the monitor is in power saving mode, the LED power indicator will change color. Refer to the Power
indicator table (see page 64).
When [DISABLE] is selected, the monitor doesn't go into power saving mode.
The monitor will enter the state selected for [MODE] in the following condition:
The monitor is powered off by pressing the main power switch or POWER ON button on the remote
control, [POWER] in [SCHEDULE INFORMATION], or by an external control.
Please refer to the monitor's specifications (see
power consumption information.


NOTE: • When the monitor is connected to a computer, the computer's display adapter may not stop
sending digital data even though there is no image on-screen. If this occurs the monitor will not
switch into standby mode.

•
The [POWER SAVE] function is disabled when [AUTO OFF] is turned on in the SCHEDULE
menu, or when [HUMAN SENSING]*
CONTROL menu.


* : The function is available only when connecting the optional sensor unit.
1
Sets the amount of time the monitor should wait for input signal before going into power save mode.
When [LOW POWER] is selected, the monitor cannot detect an input signal from the connected device will
not turn on automatically. To turn on the monitor, please press the main power switch on the monitor or the
POWER ON button on the remote control, or disconnect and reconnect the device's signal cable.
When [NORMAL] is selected, the monitor turns on by detecting an input signal from a connected device.
Please set to [NORMAL] when using an external control function (see
Select [ON] to supply power during standby.
Select [ON] to supply power to the USB port.


NOTE: Power consumption by devices connected to this port depends on the USB devices.
Shows a message as the monitor is entering low power mode.
When [ENABLE] is selected, the monitor will quickly return to the [ON] state when a signal is detected.
Enabling this option increases standby power consumption.
When [AUTO] is selected, the fans will only turn on when the internal temperature reaches the temperature
set at any one of the sensors in this menu. The fans will automatically turn off when the monitor is cooler.
When [ON] is selected the fans are always on. The fans cannot be turned off manually.
The cooling fan starts when the internal temperature exceeds the temperature set or when [FAN
CONTROL] is set to [ON].
The [FAN SPEED] can be adjusted [LOW] or [HIGH].
Shows the status of the internal temperature of the monitor.
Shows the status of the monitor's internal fan.
Shows the internal temperature of the monitor.
Shows the internal temperature of the Option Board.
Shows the status of the fan for the Option Board.
Shows the internal temperature of the Option Board.
Show the requirement operation from the Option Board.
This function is not available.
"C750Q" on page 67
is enabled in the [AUTO DIMMING] section of the
1
English−82
and "C860Q" on page 68) for
page 50).
