Storing Data

1. Press and hold the Store button on the main screen for 2 seconds or press Store
Screen on the Setting screen to configure your stored data files.
Fig. 23—Use the Store Options screen to save a data file.
2. Press New Plate to clear any recorded data on the preview screen and from
memory.
CAUTION: This will clear any readings saved in the preview grid.
3. Press File Name to enter a unique name for your data file. In the entry page, select
Clear, then type the file name, and press Enter when you finish. If you choose to
use your file name, auto-indexing must be disabled.
Fig. 24—Press Clear. Type the desire name. Press Enter.
4. If you prefer to use the Auto Index function, press Store Prefix to enter a unique
file name that will be appended with sequential numbers each time your file is
saved. Select the Auto Index radio button to enable the Store Prefix and Auto Index
buttons.
5. Press Auto Index if you want the EVOM™ Manual to automatically number
the new data files sequentially. Auto indexing changes the name to a numeric
sequence formatted with a prefix and a sequential number (prefixN).
6. Press Store Now to save the current data set. There is a time out if the USB write
fails. If this error occurs, the "Saving file..." notice will not change to "File saved."
A file is typically saved in less than 20 seconds. If your file does not save, press
Return and try using a different USB drive.
7. Press Return.
