- Page 1 WORLD PRECISION INSTRUMENTS INSTRUCTION MANUAL PM01, PM015, PM100 Hand-held monitors for vacuum and pressure measurement Serial No._____________________ www.wpiinc.com 121219...
-
Page 3: Table Of Contents
PM01, PM015 & PM100 CONTENTS ABOUT THIS MANUAL ........................1 INTRODUCTION ..........................1 Unpacking ........................... 2 INSTRUMENT DESCRIPTION ......................2 Controls ............................2 OPERATING INSTRUCTIONS ......................3 Power up ............................. 3 Fluid connections ........................3 Differential readings ......................... 3 What fluids can be used? ......................3 Selecting the range ........................ - Page 4 World Precision Instruments...
-
Page 5: About This Manual
PM01, PM015 & PM100 ABOUT THIS MANUAL The following symbols are used in this guide: This symbol indicates a CAUTION. Cautions warn against actions that can cause damage to equipment. Please read these carefully. This symbol indicates a WARNING. Warnings alert you to actions that can cause personal injury or pose a physical threat. -
Page 6: Unpacking
Concealed damage should be reported at once to the carrier and an inspection requested. Please read the section entitled “Claims and Returns” on page 7 of this manual. Please contact WPI Customer Service if any parts are missing at 941.371.1003 or customerservice@wpiinc.com. -
Page 7: Operating Instructions
PM100 the proof pressure is 150 psi (1035 kPa); for the PM015 the proof pressure is 30 psi (1550 mmHg); for the PM01 the proof pressure is 20 psi (1035 mmHg). For standard operation, pressure tubing should be connected to Port B, which will give readings of the correct sign, positive or negative, on the meter. -
Page 8: Selecting The Range
Connection is made via a mini-phone plug (0.141” outer diameter). A mini-phone-to-BNC cable is available (WPI #CLB102). For the PM01 Pressure Monitor the Record output is 300 mV/psi (±0.3 V full scale); for the PM015 Pressure Monitor the Record output is 100 mV/psi (±1.5 V full scale); for the PM100 the output is 10 mV/psi (±1 V full scale). -
Page 9: Charging The Batteries
Weight ............0.5 lbs (0.25 kg) PM Series Pressure Monitors come with 4 ft of 1/8” ID soft vinyl tubing. A mini-phone- to-BNC cable for the Record output (WPI #CLB102) is optional. Non-rechargeable versions contain one 9V alkaline battery. Rechargeable versions come with one nickel/ cadmium battery and a 120/240V-switchable battery charger. -
Page 10: Appendix A: Pressure Conversions
APPENDIX A: PRESSURE CONVERSIONS in. H2O in. Hg mBar cm H2O mmHg 1.000 27.680 2.036 6.8947 68.947 70.308 51.715 in. H 0.036127 1.0000 0.073554 0.2491 2.491 2.5400 1.8683 in. Hg 0.4912 13.596 1.000 3.3864 33.864 34.532 25.400 0.14504 4.0147 0.2953 1.000 10.000 10.1973... -
Page 11: Warranty
WPI shall not be liable for any damage to data or property that may be caused directly or indirectly by use of this product. - Page 12 175 Sarasota Center Blvd., Sarasota FL 34240-9258 Tel: 941-371-1003 • Fax: 941-377-5428 • E-mail: sales@wpiinc.com 1 Hunting Gate, Hitchin, Hertfordshire SG4 0TJ Tel: 44 (0)1462 424700 • Fax: 44 (0)1462 424701 • E-mail: wpiuk@wpi-europe.com Germany Pfingstweide 16, D-61169 Friedberg (Hessen), Germany Tel: +49 (0)6031 67708-0 •...
