Date/Time – Select the Date and Time formats for your data files.
Calibrate – Calibrate the electrode. (This uses a 10K Ω 0.1% resistor.) See "Instrument
Diagnostics and Calibration" on page 20.
Probe Null – Neutralize the offset charge on V
Store Screen– Store data files, configure how the files are named and if they are
automatically numbered.

Plate Selection Page and Plate Preview

1. Press Select Plate on the Setup page to access the Plate Selection screen.
Fig. 7—Choose the number of wells and the sampling pattern.
2. Select the radio button for the number of wells in your plate.
3. Select the sampling pattern from the options in the bottom half of the window.
4. Press Return to save the setup. When you press Preview from the main screen
you will see the plate preview files like the samples below.
Fig. 8—(Left) 6-well plate preview
Fig. 9—(Right) 12-well plate preview
Fig. 10—(Left) 24-well plate preview
Fig. 11—(Right) 48-well plate preview
10
