Configuring ATM Interfaces

Configuring SVCs

To configure the ATM interface with switched virtual circuits (SVCs), follow this procedure:
Command
Step 1
Router> enable
Password: password
Router#
Step 2
Router# configure terminal
Enter configuration commands, one per line.
End with CNTL/Z.
Router(config)#
Step 3
Router# ip routing
Router# appletalk routing
Router# ipx routing
Step 4
Router(config)# interface atm 1/0
Router(config-if)#
Step 5
Router(config-if)# pvc 0/5 qsaal
Step 6
Router(config-if-atm-vc)# exit
Step 7
Router(config-if)# pvc 0/6 ilmi
Step 8
Router(config-if-atm-vc)# exit
Step 9
Router(config-if)# ip address 192.168.74.3
255.255.255.0
Step 10
Router(config-if)# appletalk static
cable-range 3-3
Router(config-if)# appletalk zone ZZEth
Router(config-if)# ipx network B005
Step 11
Router(config-if)# svc nsap
BC.CDEF.01.234567.890A.BCDE.F012.3456.7890.
1234.12
Step 12
Router(config-if-atm-vc)# protocol ip
200.200.200.2 broadcast
Step 13
Router(config-if-atm-vc)# exit
Step 14
Router(config)# Ctrl-z
Software Configuration Guide for Cisco 2600 Series, Cisco 3600 Series, and Cisco 3700 Series Routers
3-22
Chapter 3 Configuring with the Command-Line Interface
Purpose
Enter enable mode. Enter the password.
You have entered enable mode when the prompt
changes to .
Router#
Enter global configuration mode. You have
entered global configuration mode when the
prompt changes to
Router(config)#.
Enable routing protocols as required for your
global configuration. This example uses IP
routing, AppleTalk routing, and Internetwork
Packet Exchange (IPX) routing.
Enter interface configuration mode. You have
entered interface configuration mode when the
prompt changes to
Router(config-if)#.
Configure a signaling channel for the SVC.
Exit back to interface configuration mode.
Configure additional signaling channels for the
SVC.
Exit back to interface configuration mode.
Assign an IP address and subnet mask to the
interface.
Configure routing protocols on the interface. You
must have previously enabled these protocols as
part of global configuration. In this example,
AppleTalk and IPX are being configured on the
interface.
Configure the signaling PVC and the ATM
network service access point (NSAP) address. The
signaling PVC command has the format svc
[name] nasp <20-byte address>. You have
entered interface-ATM-VC configuration mode
when the prompt changes to
Router(config-if-atm-vc).
Map the PVC to an address.
Exit back to global configuration mode.
Repeat Step 4 through Step 12 if your router has
more than one interface that you need to
configure.
When you finish configuring interfaces, return to
enable mode.
