Overview
2.5 System components
Additional information
You can find information on mounting the PRO device at Prepared for support arm and
extension elements (flange mount) (Page 36).
You can find Information on available accessories on the Internet at:
• Industry Mall (https://mall.industry.siemens.com)
See also
Prepared for support arm or stand without extension elements (flange on top) (Page 33)
System components for devices with all-round IP65 protection
(https://mall.industry.siemens.com/mall/en/WW/Catalog/Products/10299123?tree=CatalogTre
e)
2.5.3

Adapter set for support arm and stand mounting of PRO device

The PRO device can be mounted on systems from third-party vendors (see section "Mounting
the device (Page 32)"). For this you will need the Siemens base adapter (see Base adapter
(Page 16)) and a proprietary adapter set.
Siemens also offers its own adapter for VESA-compatible third-party systems:
Adapter set
SIEMENS:
•
•
RITTAL:
Adapter for
Siemens PRO-Panel
•
•
ROLEC:
Adapter for
Siemens PRO-Panel
•
•
BERNSTEIN:
Coupling for Siemens SIMATIC
PRO
•
•
Information provided without guarantee.
18
Adapter set VESA75
Adapter set VESA100
Intermediate plate
Screws
Intermediate plate
Screws
No intermediate plate re-
quired
Coupling with integrated
adaptation for PRO device
Suitable for support arm systems Article number
• VESA75-compatible systems
• VESA100-compatible systems
• CP40 steel
• CP60/120 for
Support arm connection
120 × 65 mm
taraPLUS for ∅ 65 mm hole
• profiPlus-50
•
circle
• CS-3000
Operating Instructions, 08/2024, A5E39912462-AF
• 6AV7674-0KE00-0AA0
• 6AV7674-0KD00-0AA0
• 6206.500
• 142.024.000
• 1015300187 RAL 9006
white aluminum
• 1015300043 RAL 7016
anthracite gray
SIMATIC IPC477E PRO
