Overview

2.5 System components

2.5 System components
2.5.1

Base adapter

PRO devices of the type "suitable for support arm" or "suitable for stand" can be mounted on a
support arm or stand using the base adapter. Depending on the support arm system used, an
adapter plate may have to be installed in addition (see Accessories (Page 15)).
A base adapter is included with the corresponding PRO devices. The base adapter can also be
ordered separately.
①
②
③
④
⑤
Article number for the base adapter as accessory: 6AV7674-1KA00-0AA0.
See also
Prepared for support arm or stand without extension elements (flange on top) (Page 33)
Industry Mall (https://mall.industry.siemens.com)
Expansion components and accessories
(https://mall.industry.siemens.com/mall/en/WW/Catalog/Products/10144445)
System components for devices with all-round IP65 protection
(https://mall.industry.siemens.com/mall/en/WW/Catalog/Products/10299123?tree=CatalogTre
e)
16
Seal
Cable channel
Mechanical interface to the PRO device
Cover
Mechanical interface to support arm or stand
