- Page 1 TN-4500B Series Quick Installation Guide Moxa ToughNet Managed Switch Version 1.0, September 2024 Technical Support Contact Information www.moxa.com/support 2024 Moxa Inc. All rights reserved. P/N: 1802045003010 *1802045003010*...
-
Page 2: Package Checklist
NOTE When installed according to the Quick Installation Guide (QIG) and used under the conditions specified in the datasheet, Moxa products require no maintenance. Package Checklist Your ToughNet TN-4500B Series managed switch is shipped with the following items: • TN-4500B Series managed switch •... -
Page 3: Panel Layouts
Panel Layouts The diagrams here show the TN-4516B model. Interface combinations and numbers vary depending on the models in the series. 1. Model name 2. Wall-mounting kit aperture (M4) 3. USB storage port (M12 A-coded 5-pin female connector) 4. Grounding screw (M6) 5. - Page 4 Port Layout and Indicators The TN-4500B Series models come with labels/indicators next to all ports including Gigabit Ethernet, PoE, and bypass ports. Ports are numbered from bottom to top and left to right. Depending on the model that you have purchased, the size and layout of the front panel will vary.
-
Page 5: Led Indicators
Model Port No. Bypass Port Ports Sets TN-4520B-12P-4GP-4GBP-CT-T 1 to 12 1 to 12 G5, G6 (Set 1) G1 to G8 G1 to G4 G7, G8 (Set 2) TN-4528B-20P-4G-4GP-CT-T 1 to 20 1 to 20 G1 to G8 G1 to G4 TN-4528B-20P-4GP-4GBP-CT-T 1 to 20 1 to 20... - Page 6 Color State Description The system passed the self-diagnosis test during bootup and is ready to run Blinking System service is initializing (1 Hz) Green Blinking An external storage is connected to the (4 Hz) switch STATE The system has initially failed the bootup process System info read fail/ EEPROM information error...
- Page 7 Dimensions TN-4508B Models TN-4512B non-PoE Models - 7 -...
- Page 8 TN-4512B PoE Models TN-4516B non-PoE Models - 8 -...
- Page 9 TN-4516B PoE Models - 9 -...
- Page 10 TN-4520B Models - 10 -...
-
Page 11: Wall Mounting
TN-4528B Models Wall Mounting STEP 1: Mounting the TN-4500B to a wall requires 4 screws. Use the keyhole-shaped apertures of the switch as a guide to mark the positions of the 4 screws on the wall. STEP 2: Use the 4 screws in the wall mounting kit and drive them into the wall at the points marked on the wall. -
Page 12: Wiring Requirements
NOTE Before fixing the screws on to the wall, make sure the screw head and shaft size are suitable by inserting the screw through the keyhole-shaped apertures of the switch. STEP 3: After fixing the mounting screws to the wall, align the screw holes of the keyhole-shaped apertures of the mounting kit with the screws and slide the switch up/down based on installation situation. - Page 13 Please Read and Follow These Guidelines • Use separate paths to route wiring for power and devices. If power wiring and device wiring paths must cross, make sure the wires are perpendicular at the intersection point. NOTE Do not run signal or communications wiring and power wiring through the same wire conduit.
-
Page 14: Connecting The Power Supplies
Connecting the Power Supplies The ToughNet TN-4500B Series managed switches support dual power inputs—power input 1 and power input 2. The M12 K-coded 5-pin male connector on the TN-4500B’s front panel is used for the dual power inputs. Pinouts for the Power Input Port V1–... - Page 15 ATTENTION This equipment is intended to be supplied by an external power source (UL listed/IEC 60950-1/IEC 62368-1). The TN-4500B Series requires an output rating of 24 to 110 VDC at an ambient temperature of min. 70°C. The minimum current rating varies for the different TN-4500B Series models as listed below: •...
-
Page 16: Connecting The Data Lines
Connecting the Data Lines 10/100BaseT(X) Ethernet Port Connection The TN-4500B switches come with 4-pin shielded M12 D-coded connectors on the 10/100BaseT(X) Ethernet ports. These ports are located on the front panel and are used to connect to Ethernet-enabled devices. Most users configure these ports for Auto MDI/MDI-X mode, in which case the port’s pinouts are adjusted automatically depending on the type of Ethernet cable used (straight-through or cross-over), and the type of device (NIC-type or HUB/Switch/Router-type) connected to... -
Page 17: Connecting To The Serial Port
PoE Pinout D-coded X-coded Pin 1, 3 (TD+, TD-) Pin 1, 2 (DA+, DA-) Pin 2, 4 (RD+, RD-) Pin 3, 4 (DB+, DB-) PoE Output Power for IEEE 802.3at/af Compliant PoE Ports Output per port: 30 W Total PoE Budget TN-4512 PoE models: 80 W TN-4516/20/28B PoE models : 150 W ATTENTION... - Page 18 Connecting to the USB Storage Port The TN-4500B Series has a M12 A-coded 5-pin female connector. Users can either use an adapter or the ABC-02-P-USB-M12 to connect to a PC or to import configuration files to the device. NOTE We recommend the ABC-02-P-USB-M12-CT-T USB storage for storing and load the configuration.
- Page 19 BSMI—限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：網管交換機 型號（型式）:TN-4500B (及其系列型號) Equipment name Type designation (Type) 限用物質及其化學符號 單元Ｕnit 鉛 汞 鎘 六價鉻 多溴聯苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr+6) (PBB) (PBDE) 外殼 ○ ○ ○ ○ ○ ○ 印刷電路板及其電子組件...
