User Manual
ATEX / UKEX Certified Variable Axial Piston Pumps for Industrial Applications – PVM 18 – 141 cc
Introduction
General Information
Purpose of this Document
This User Manual has been prepared by the manufacturer in order to provide important information
regarding the safe installation, operation and maintenance of ATEX / UKEX certified pumps. The items set
out within this document are mandatory unless stated otherwise.
This User Manual is a supplement to existing product instruction as ATEX / UKEX components are
subjected to some limitations compared to standard components. The limitations are described in this
instruction. Items or limitations within this document override any contradictory information which may
be found in the product catalog.
It is intended for machine/system manufacturers, fitters and service technicians. Please read this User
Manual carefully before you work with and start-up the pumps.
This User Manual must be stored in close proximity to the pumps.
Product Description
PVM pumps are a range of variable displacement, high power open circuit pumps designed for industrial
applications. They feature a swashplate design with a maximum continuous working pressure of 315 or
230 bar. They can be supplied in "higher speed" or "quiet" versions.
Manufacturer Responsibility
The manufacturer declines any responsibility in case of:
•
•
•
•
•
•
Product Safety
The safety of the product depends upon the strict observation of the indications given in this User
Manual: in particular, it is necessary to:
•
•
•
•
•
Intended Use
Hydraulic pumps convert mechanical energy (torque and speed) into hydraulic energy (pressure, oil flow).
PVM pumps are designed for industrial applications.
The pumps fulfill the explosion requirements of the Directive 2014/34/EU and UKEX SI 2016 No. 1107 for
the category shown on the name plate within the limiting conditions mentioned within this user manual
or product catalog/ technical information.
PVM pumps have an identifying name plate. The name plate provides essential information and
specification for correct and safe use.
This identifying plate has to be maintained so that the data can be clearly read; consequently, a periodic
cleaning of the plate is required. If the nameplate or other labels need to be removed for maintenance or
service, they need to be reinstalled before the pump is being recommissioned.
Marking of Vickers by Danfoss PVM Pumps
The PVM hydraulic pumps are marked as equipment for Group II, category 3 for gas environment and with
ignition protection constructional safety and liquid immersion.
Temperature class/Maximum surface temperature depends on the operating conditions (ambient and
fluid temperature) as well as application duty cycles.
4 | Vickers by Danfoss | January 2024
Use of the product not according to safety regulations and legislation valid in the user's country.
Use of the product in operating conditions not allowed according to the product technical
information.
Improper installation: the instructions given in this User Manual are not followed or not properly
followed.
Hydraulic system problems.
Modification of the product.
Operations executed by personnel not properly trained or not assigned to such a kind of operations.
Always operate within allowed product working operating conditions (please refer to the Technical
Information of the pumps in usage).
Always perform an accurate ordinary maintenance activity.
Assign the inspection activity as well as maintenance activity to duly trained personnel.
Only use original spares.
Always use the product according to the indications you find in this manual.
BC479055194216en-000101
