MODEL 1036-230
MEDIUM SIZE
NECROPSY TABLE
CAUTION
• Inspect unit and all components
for any loosening that may have
occurred during shipping •
ATTENTION
Review entire manual before
starting assembly
Mortech™ Manufacturing Inc.
411 North Aerojet Avenue, Azusa, CA 91702
(626) 334-1471 www.mortechmfg.com
™
Technical Users' Manual
Installation and Operating Instructions
ISO Doc. #OM1036-230 (REV A)
JUNE 2011
Advertisement
Table of Contents
Related Manuals for MORTECH 1036-230
Summary of Contents for MORTECH 1036-230
- Page 1 ™ Technical Users’ Manual Installation and Operating Instructions MODEL 1036-230 MEDIUM SIZE NECROPSY TABLE CAUTION • Inspect unit and all components for any loosening that may have occurred during shipping • ATTENTION Review entire manual before starting assembly JUNE 2011 Mortech™...
-
Page 2: Safety Information
BE SURE TO CHECK WARNING • Are all components present? It is crucial that any work performed on Mortech Mfg. Inc. • Do the moving parts operate smoothly? manufactured items are carried out exclusively by skilled • Is unit draining properly? professionals who have the respective training. -
Page 3: Installation Instructions
BASE MOUNTING HOLES (4) Ø BASE MOUNTING HOLES INSTALLATION INSTRUCTIONS Drawings from Mortech for utilities are provided with the submittal packet information. Utilities can include: water lines, electrical, etc. PREPARING THE BUILDING FLOOR A .ø8" RADIUS AREA FOR EXHAUST CONNECTION WHERE UNIT IS TO BE PLACED Step 2. - Page 4 Installation 1036-230 Medium Sized Necropsy Station A .ø8" RADIUS AREA FOR EXHAUST CONNECTION A 4"x5" AREA FOR INLET PLUMBING A 4"x4" AREA FOR ELECTRICAL INPUT A .8" RADIUS AREA FOR WASTE PLUMBING PLUMBING CONNECTION INSTRUCTIONS Step 2: Connect drain line to sink basin or disposal unit, STEP 1: (Refer to Figure-G) Flush out all water lines prior depending on the option provided.
-
Page 5: Electrical Connection Instructions
1036-230 Medium Sized Necropsy Station Installation PLUMBING CONNECTION CONT... ELECTRICAL CONDUIT HOT WATER COLD WATER CONNECT TO BUILDING DRAIN ELECTRICAL CONNECTION INSTRUCTIONS Step 1: (Refer to Figure-I) Connect electrical lines from ASCO Red Hat #8210G073 Solenoid station to building. Units are provided with watertight Solenoid is located underneath unit. - Page 6 Electrical 1036-230 Medium Sized Necropsy Station 1036-41 ELECTRICAL CONNECTION INCOMING MAIN MAIN ELECTRICAL POWER POWER POWER DISCONNECT DISCONNECT (CONDUIT) GFCI DISPOSAL DISPOSAL GFCI RECEPTACLE SWITCH SWITCH RECEPTACLE SOLENOID SOLENOID DISPOSAL DISPOSAL VALVE VALVE DISPOSAL INCOMING ELECTRICAL POWER (CONDUIT) MAIN POWER...
-
Page 7: Parts Listing
1036-230 Medium Sized Necropsy Station Parts listing DOWNDRAFT VENTILATION CAUTION VENTILATION ACCESS PANEL -Located beneath the sink ( on all three sides). Liquid has the potential to deposit within the ventilation system. MORTECH RECOMMENDS CLEANING MONTHLY DOWNDRAFT VENTILATION DOWNDRAFT VENTILATION... - Page 8 Parts listing 1036-230 Medium Sized Necropsy Station CAUTION- When removing and replacing VENTILATION ACCESS PANEL Do not over tighten. The gasket may be damaged To access ventilation system remove the screws on the panels gently lift off the panel. DOWNDRAFT VENTILATION Ventilation system to allow relief from the dissecting areas.
-
Page 9: Optional Accessories
1036-230 Medium Sized Necropsy Station Parts listing HOT/COLD MIXING FAUCET (2) LARGE SINGLE w/WRIST BLADE HANDLES COMPARTMENT SINK BASINS GOOSENECK SWING NOZZLE w/DOWNDRAFT VENTILATION (USE LEVERS TO TEMPER WATER) LOCATED INSIDE SINK DISSECTING PERFORATED GRID TIE DOWN TRACK (6) ACCESS PANELS... -
Page 10: Troubleshooting
- If above two are adequate, disassemble unit and check for Sink not draining debris causing a clog in the unit. - Check for debris in sink area - Call Mortech customer service if problem persists - Contact plumber to diagnose and clear Disposal not functioning drain if problem persist... - Page 11 1036-230 Medium Sized Necropsy Station Parts listing TIE DOWN TRACK STUD RING FITTING STUD RING FITTING TIE DOWN TRACK JUNE 2011 MFGISO DOC. #OM1036-230 (REV A)
- Page 12 Parts listing 1036-230 Medium Sized Necropsy Station CIRCULAR PIN OVAL PLACEMENT RESTRICTED SLOT When collar is raised, place circular pin Stud Ring Fitting locked into position. in the oval placement. Slide toward the restricted slot and release collar. The stud ring fitting will lock in place.
- Page 13 1036-230 Medium Sized Necropsy Station Parts listing TIE DOWN TRACK COLLAR 1. By taking the collar and pulling it 4. By taking the collar and pulling it toward the toward the ring you will be ready to ring you can adjust the stud ring fitting up and attach to the tie down track.
- Page 14 1036-230 Medium Sized Necropsy Station Accessories Digital Scale Removable Measuring Ruler The Ohaus Compact Scale Anyone who works with is ideal when cost matters metal will appreciate the and dependable results are simplicity and practicality a must. This uniquely designed...
-
Page 15: Component Data
(123.8 mm) (431.8 mm) 6-3/8" (161.9 mm) SOLENOID 1-1/2" 6-13/16" (38.1 mm) (173.0 mm) EXTERNAL ELECTRICAL CONNECTIONS ASCO Red Hat #8210G073 Solenoid Solenoid is located underneath unit. Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com... -
Page 16: Specifications
INSINKERATOR DIVISION OF EMERSON ELECTRIC COMPANY 4700 21st STREET RACINE, WI 53406 TEL: 414 554-5432 1-800-558-5712 FAX: 414 554-8917 For additional information, see Commercial Product Information Binder. Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com... - Page 17 Insinkerator Heavy Duty Disposal Heavy duty disposal OPERATING INSTRUCTIONS The Insinkerator commercial food waste disposer is UL Listed when installed in conjunction with Operating the Disposer Insinkerator mounting adapters and controls 1. Make sure there are no foreign objects in the disposer (see Figure 1 below for a typical installation).
- Page 18 Insinkerator Heavy Duty Disposal Heavy duty disposal ELECTRICAL Property Damage These plumbing instructions were written for an experienced WARNING - Electrical Shock competent installer. If the installer is not experienced in • Turn off the electrical supply to the disposer before plumbing installation, Insinkerator recommends that servicing.
- Page 19 Insinkerator Heavy Duty Disposal Heavy duty disposal INSTALLING THE DISPOSER (8) onto the lip. 6. Place the mounting gasket WARNING (11) on the disposer body flange. Secure the mounting flange Personal Injury (10) to the disposer body flange with six screws (12) pro- •...
- Page 20 Insinkerator Heavy Duty Disposal Heavy duty disposal • The disposer motor wiring connection is shown in the Commercial disposer accessories are included in this disposer terminal box. warranty only if they are included in the original disposer purchase package. DANGER Electrical Shock •...
- Page 21 Insinkerator Heavy Duty Disposal Heavy duty disposal TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION The disposer will not start No incoming power. Turn on electrical supply. and water does not flow. The disposer will not start The disposer overload Turn control to the off position and press but water flows.
- Page 22 CAUTION: Solenoid must be fully reassembled as the hous- ing and internal parts are part of and complete the magnetic circuit. Place insulating washer at each end of coil if required. Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com...
-
Page 23: Product Features
120/277 Volt HP Rating: 1HP-120V 2HP-240V-277V Max Amp: 16 Amp Termination: Side Actuator Material: Thermoplastic Body Material: Thermoplastic Strap Material: Steel Standards and Certifications: UL/CSA 110V 220V Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com... -
Page 24: Material Characteristics
RESET LINE LINE LINE LINE: cable brings power to the GFCI Service Panel Mortech™ Manufacturing Inc. Grounding connection to box ( if box has a grounding terminal) LOAD LOAD 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com Wire... - Page 25 • Patented Quick-Fit™ Key Hole Mount for Easy Installation • Patented Universal-Fit™ Adapter Technology • Lockable Tab • Premium Powdercoat Finish • Spring Hinge Closure • UL Listed & 2008 NEC Compliant Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com...
-
Page 26: Technical Specifications
Markings The outer surface of the conduit shall be clearly marked with a legible print legend in accordance with UL 1660 and CSA C22.2 No. 227.2. Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com... - Page 27 T&S SWIVEL GOOSENECK SPIGOT WALL MOUNT FAUCET Model #135X HOT/COLD MIXING FAUCET T&S DECK MOUNT FAUCET w/GOOSENECK NOZZLE Model #B-0225-LN T&S DECK MOUNT FAUCET w/WRIST BLADES Model #B-0225-LN Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com...
- Page 28 SPRAY HOSE ASSEMBLY SINGLE WALL CONTROL VALVE Model #2700 SPRAY HEAD Model #10820 SPRAY HANDLE Model #2913 SPRAY HOSE Mortech Model #SH10 SPRAY HOSE Mortech Model #SH10 FISHER SINGLE WALL CONTROL VALVE MODEL # 2700 Feature: • Single wall • Stem - right hand •...
- Page 29 Std. 1013; AWWA Std. C511; CSA B64.4. Shall be a Watts Regulator Co. Series 009. †Does not indicate approval status. Refer to Page 2 for approved 1 Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com...
- Page 30 Plug: ................Bronze Gasket:................NBR Standard Screen: ....#20 mesh, 304 stainless steel D WYE STRAINER PLUMBED INTO A 1036-230 IMPORTANT Before Service and Maintenance: Shut water off before checking and cleaning the Wye Strainer fitting screen located inside the fitting.
-
Page 31: Maintenance Instructions
1036-230 Medium Sized Necropsy Station Maintenance MAINTENANCE INSTRUCTIONS Shop Oil and Grease - These soils may be corrosive and may not allow the surface to maintain passivity, and so MAINTENANCE SCHEDULE removal is a necessity. Soap or detergent and water may be The unit requires regular maintenance and follow the used or a combination of detergent and water plus a solvent. -
Page 32: Maintenance Record
Maintenance record 1036-230 Medium Sized Necropsy Station MAINTENANCE RECORD Date JUNE 2011 MFGISO DOC. #OM1036-230 (REV A) -
Page 33: Training Record
1036-230 Medium Sized Necropsy Station Training record TRAINING RECORD Date JUNE 2011 MFGISO DOC. #OM1036-230 (REV A) -
Page 34: Warranty
Customer Relations. FAX (626) 334-1704 www.mortechmfg.com PROPRIETARY NOTICE info@mortechmfg.com The information in this manual is the property of Mortech © COPYRIGHT MORTECH MANUFACTURING INC., ALL Manufacturing. Mortech Manufacturing reserves all patent RIGHTS RESERVED. rights, proprietary design rights, manufacturing rights,...
