Circontrol Wallbox eVolve Rapid Series Installation & User Manual page 28

Wallbox eVolve Rapid Manual
7
General Specifications
24
AC Power Supply
AC Input Voltage
Power Factor
Efficiency
Frequency
Required power supply capacity
Maximum AC input current
Maximum output power
Maximum output current
Output voltage
Compliance
Enclosure material
Enclosure rating
Operating Humidity
Ambient temperature storage
Lights for status indication
Enclosure door lock
Enclosure access
Charge cable length
MID
3P + N + PE
400V +/- 10% three-phase
> 0.98
94% at nominal output power
50 / 60Hz
27 kVA
39 A
25 kW
70 A
150-920 Vdc
CE / Combo-2
(DIN 70121; ISO15118)
IEC61851-1; IEC61851-23
IEC61851-21-2
Aluminium & ABS
IP54 & IK10
Up to 95%
-40 ºC to +60 ºC
RGB colour indicator
Security key lock
Frontal door
5.5 meters
Class 1 - EN50470-3
