Paper Jams In The Output Area (Mf8350Cdn Only) - Canon Color imageCLASS MF8050Cn Basic Operation Manual

4
Remove the paper by pulling it gently.
Make sure that no paper is jammed inside the paper output guide,
and then close it.
5
Remove the paper by pulling it gently.
6
Holding the tabs (A) on both sides, close the
duplex unit.
Close the guide firmly until it clicks.
(A)
7
Remove the paper by pulling it gently.
8
Close the rear cover.
The machine is ready to print.
Paper Jams in the Output Area (MF8350Cdn
Only)
Referring to the procedure on the display, follow the steps
below to remove jammed documents.
Keys to be used for this operation
1
2
(A)
3
4
5
Press [ ].
Paper jam.
Press [ ] to
display steps.
Open the front cover.
Lift the scanning platform.
Remove the paper by pulling it gently.
Lower the scanning platform.
9-7
