Starter Guide
Read This Manual First.
Be sure to read the manual before using the
machine.
The remarks for important safety
instructions are described in "Basic
Operation Guide." Read the manual also.
Keep the manual for future reference.
1
2
3
4
Preface
Next Page
Installing the Machine
P. 4
Configuring and
Connecting the Fax
P. 11
Connecting to a Computer
and Installing the Drivers
P. 15
Appendix
P. A-1

Advertisement

Table of Contents
loading

Related Manuals for Canon Color imageCLASS MF8350Cdn

Summary of Contents for Canon Color imageCLASS MF8350Cdn

  • Page 1 Connecting the Fax P. 11 Connecting to a Computer and Installing the Drivers P. 15 Read This Manual First. Be sure to read the manual before using the Appendix machine. The remarks for important safety P. A-1 instructions are described in "Basic Operation Guide."...

  • Page 2: Setting Up

    Setting Up the Machine to Suit Your Purposes Determine which machine functions (Copy, Print, Fax, PC Fax, Scan, Remote UI) you intend to use, and make the settings according to the flowchart below. Remote Network Connection Connection Print Print Settings from...

  • Page 3: About The Supplied Toner Cartridge

    The average yield is on the basis of "ISO/IEC 19798"* when printing A4 size paper with the default print density setting. "ISO/IEC 19798" is the global standard related to "Method for the determination of toner cartridge yield for color printers and multi-function devices that contain printer components"...
  • Page 4 Canon fax driver as a printer, and specify the output destination and options. The fax driver convert the data into an image that conforms to standard fax protocols so that the data can be printed or saved using the recipient’s fax machine.

  • Page 5: About The Supplied Manual

    Various Functions Registering a Destination in the • Appendix Address Book • Using the Fax Functions e-Manual The e-Manual is included in the User Software CD-ROM. • • Setting and Managing from Basic Operation Read the desired chapter • Computer Copy to suit your needs.

  • Page 6: Remove The Packing Materials

    Carry the machine with two or more people. Hold the lift handles. Remove the packing materials. The packing materials may be changed in form or placement, or may be added or removed without notice. A loud noise occurs when you open the rear cover or remove the packing materials with tape.
  • Page 7 Tape Packing materials with tape Packing materials with tape Preparing the Toner Cartridges Open the front cover to pull out the toner cartridge tray. Press the lever. Open the front cover. Pull out the toner cartridge tray.

  • Page 8: Loading Paper

    Check! Did you remove all the Sealing tape packing materials? Push the toner cartridge tray, and then close the front cover. Push the toner cartridge tray. Close the front cover. Loading Paper Load paper in the paper cassette.
  • Page 9 Adjust the length of the paper cassette. • When changing the size of the paper to be loaded Be sure to register the paper size. → "Setting a Paper Size and Type" (P. 10) Load the paper. Hold the lock release...

  • Page 10: Connecting The Power Cord

    Plug the power plug into the AC power socket. power outlet. Do not connect the USB cable. Connect the USB cable when installing the software. Turning the Power ON and Specifying the Initial Settings Turn ON the power of the machine.
  • Page 11 [OK]. • Is the test chart placed on the platen glass correctly? → Place the test chart with the printing side face down and the black streak toward Supported paper: the back of the machine. Size: A4, LTR, 16K •...

  • Page 12: Setting A Paper Size And Type

    Setting a Paper Size and Type Press [ ] (Paper Select/ Select with [ ] or [ ], and then Select with [ ] or [ ], and then Settings). press [OK]. press [OK]. Select Paper Paper Settings MP Tray...
  • Page 13 • Setting the fax receive mode • Connecting a telephone line If you are using a pulse dialing, change the line type after specifying the settings. Text Input Method Entering letters and symbols Enter information into the machine using the Enter with numeric keys or [ ] (Symbols).
  • Page 14 Set the fax receive mode. You can specify how the machine should operate for a fax call or telephone call. By answering the questions that appear on the display, the machine is set to any one of the following four* operation modes. <Auto><Fax/Tel><Answer><Manual> You can set a receive mode other than the above manually depending on your country or region. For details on the setting procedure, see "Receiving Faxes" in the e-Manual. The <Auto> mode is set. → Proceed to Step 3. Do you want to use • Receives a fax automatically. this machine for fax • Does not use the telephone.* only (no telephone)? <Yes> <No> If connecting with the telephone in the auto receive mode, the telephone rings when receiving a fax or telephone call. You can answer the telephone while the telephone is ringing. To configure so that the telephone does not ring, see “Incoming Ring” in the e-Manual. The <Fax/Tel> mode is set. → Proceed to Step 3. Do you want to auto- • Receives a fax automatically.

  • Page 15: Connect A Telephone Line

    Setting is complete. Guide? Turn the main power OFF and ON. Fax settings and connections have been completed. Restart the machine to activate the settings. Turn OFF the machine and wait for at least 10 seconds before turning it ON again.
  • Page 16 Change the line type. By default, the telephone line type on the machine is set to tone dialing. If you use tone dialing, skip the following procedure. If you use pulse dialing, follow the procedure below and change the telephone line type setting on the machine to pulse dialing.

  • Page 17: Selecting A Method For Connecting The Machine To A Computer

    Selecting a Method for Connecting the Machine To a Computer There are two ways to connect the machine to a computer: Network connection and USB connection, so select the connection type according to your environment or function. The functions of USB connection and network connection can be used simultaneously.

  • Page 18: Installing Via Network Connection

    IP addresses are properly set up. Turn on the computer, and then log on as a user with administrative rights. If you have already logged on, exit all the applications which are running. Install the MF Driver and MF Toolbox. Insert the CD-ROM.
  • Page 19 The device is turned on. • IP address is set correctly. • The computer and device are on the same subnet. Click [Update Device List]. If any devices are not displayed by performing the Click. above procedure, perform the following procedure.
  • Page 20 Connect the USB cable after the installation of software. • Make sure that the power of the machine is turned ON when connecting the USB cable. Turn on the computer, and then log on as a user with administrative rights.

  • Page 21: Connect The Usb Cable

    Connect to the USB port on the computer. • Rectangular end (B): Connect to the USB port on the machine. When the dialog box is displayed Follow the on-screen instructions and complete the installation. Checking the Installation Results P. 20...
  • Page 22 Checking the Installation Results Make sure that MF driver and MF Toolbox are installed correctly. Make sure that the icon of the installed software is added as follows. Software Location Icon Printer folder Printer driver • Windows 2000 From the [Start] menu, select [Settings] → [Printers].
  • Page 23 How to Use the Online Help In the Online Help, all the functions of the driver software and information about options are included. If you want to know descriptions of the functions and settings immediately when using the driver software, make use of the Online Help.

  • Page 24: Using The E-Manual

    Select only the [Manuals] check box. 2. Press the [ENTER] key on the keyboard. The CD-ROM drive name is indicated as "D:" in this manual. The CD-ROM drive name may differ depending on the computer you are using. Click [Install].

  • Page 25: Checking The Ip Address

    Check the screen of the Remote UI is displayed. When the machine is connected to a switching hub You may not be able to connect the machine to a network even though your network settings are appropriate. If you delay the startup time for the machine’s network, this may solve the problem.
  • Page 26 If You Want to Uninstall the Installed Software When you do not need the printer driver, fax driver, scanner driver, or MF Toolbox, you can uninstall it using the following procedure. Check the following points. • That you must be the user with administrative privileges •...

  • Page 27: Contacting Service Center

    Contacting Service Center When you have a problem with your machine and you cannot solve it even if you refer to the manuals or online help, please contact our Canon Authorized Service Facilities or the Canon Customer Care Center at 1-800-828- 4040 between the hours of 8:00 A.M.
  • Page 28 CANON EUROPA N.V. Bovenkerkerweg 59-61 1185 XB Amstelveen, The Netherlands CANON CHINA CO. LTD. 15F Jinbao Building No.89 Jinbao Street, Dongcheng District, Beijing 100005, China CANON SINGAPORE PTE. LTD. 1 HarbourFront Avenue #04-01 Keppel Bay Tower, Singapore 098632 CANON AUSTRALIA PTY. LTD.
