- Page 1 I-STOP I-STOP-X & I-STOP-Z Series Iron Removal Systems User Guide W A T E R T R E A T M E N T...
-
Page 2: Table Of Contents
Pro-Switch Pty Ltd Puretec Customer Service Thank you for purchasing a Puretec Water Treatment System. Your system is a proven performer manufactured from only quality materials and components. It will give years of reliability and trouble free operation, dependent on the initial installation and periodic maintenance. -
Page 3: Warnings
+ sulphate is more than half of the total alkalinity Caution: Do not use with water that is microbiologically unsafe or without adequate disinfection before or after the system. Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide... -
Page 4: Before Installation
• Install as close as possible to a drain. • Install in correct relationship to other water treatment equipment. Contact Puretec for assistance. • Install the system in the supply line BEFORE the water heater. Temperatures above 43°C will damage the system and void the warranty. - Page 5 MUST be selected to accommodate the higher flow rate, treated water volume, plus the backwashing requirements of the filter system. Contact Puretec for assistance. Copyright © Puretec Pty Ltd 2024...
-
Page 6: Installation Record
___________ ppm / mg/L Manganese: ___________ ppm / mg/L ___________ TDS (Total Dissolved Salts): ___________ ppm / mg/L Hydrogen Sulfide: ___________ ppm TOC (Total Organic Carbons): ___________ % Dissolved Oxygen: ___________ ppt Installation & Operation Manual Copyright © Puretec Pty Ltd 2024... -
Page 7: Diagram Identification
Inlet 1" Outlet 1" Outlet 1" ¾” ¾” Drain Drain Control Panel I-STOP-Z40 I-STOP-X40 Inlet 1" Outlet 1" Inlet 1" Outlet 1" 1” Drain 1” Drain Control Panel I-STOP-X70 I-STOP-Z70 Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide... -
Page 8: Individual Model Information
Bypass Valve (Optional - Sold Separately) Check Valve (pre-installed) E5 Valve Air Blocker (pre-installed) Transformer & Lead Pressure Tank UV Collar (pre-installed) Pressure Tank (Vessel) Riser Pipe & Distributor (pre-installed) Installation & Operation Manual Copyright © Puretec Pty Ltd 2024... - Page 9 Multi-media High Performance Medium 5L Media Kit WTM3200-10L Katamax Pro Media 10L (12kg) WTM3200-15L Katamax Pro Media 15L (18kg) Vessel Media Filling Order 1 x WTM7550-5L 1 x WTM3200-10L & 3 x WTM3200-15L Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide...
- Page 10 (Optional - Sold Separately) Check Valve (pre-installed) E5 Valve Transformer & Lead Air Blocker (pre-installed) Lateral (pre-installed) Pressure Tank UV Collar (pre-installed) Pressure Tank (Vessel) Riser Pipe & Distributor (pre-installed) 10 Installation & Operation Manual Copyright © Puretec Pty Ltd 2024...
- Page 11 Drain Line Flow Connector (DLFC) Drain Tube Assembly WTM7550-15L Multi-media High Performance Medium 15L Media Kit WTM3200-15L Katamax Pro Media 15L (18kg) Vessel Media Filling Order 1 x WTM7550-5L 7 x WTM3200-15L Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide...
- Page 12 (Optional - Sold Separately) Transformer & Lead Check Valve (pre-installed) Ozone Generator (pre-installed) Air Blocker (pre-installed) Pressure Tank UV Collar (pre-installed) Pressure Tank (Vessel) Riser Pipe & Distributor (pre-installed) 12 Installation & Operation Manual Copyright © Puretec Pty Ltd 2024...
- Page 13 Multi-media High Performance Medium 5L Media Kit WTM3200-10L Katamax Pro Media 10L (12kg) WTM3200-15L Katamax Pro Media 15L (18kg) Vessel Media Filling Order 1 x WTM7550-5L 1 x WTM3200-10L & 3 x WTM3200-15L Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide...
- Page 14 (Optional - Sold Separately) Check Valve (pre-installed) Ozone Generator (pre-installed) Transformer & Lead Air Blocker (pre-installed) Lateral (pre-installed) Pressure Tank UV Collar (pre-installed) Pressure Tank (Vessel) Riser Pipe & Distributor (pre-installed) 14 Installation & Operation Manual Copyright © Puretec Pty Ltd 2024...
- Page 15 Drain Line Flow Connector (DLFC) Drain Tube Assembly WTM7550-15L Multi-media High Performance Medium 15L Media Kit WTM3200-15L Katamax Pro Media 15L (18kg) Vessel Media Filling Order 1 x WTM7550-15L 7 x WTM3200-15L Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide...
-
Page 16: Installation Procedure
1" drain tube required. I-STOP-X40 & I-STOP-Z40 Models: ¾" drain tube required. Ensure Water Has Been Tested Input values into table on Page 3 and the analysis has been inspected by Puretec. Water Analysis Information Hardness ___________ ppm / mg/L... - Page 17 DO NOT install where water hammer conditions may occur without installing an arrestor. Allow sufficient space around the installation for easy servicing. Provide a non- switched 240V power source for the control valve. Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide...
- Page 18 Connect the DLFC to the valve. Vessel Media Filling Order Fill vessel with media in the following order, according to your system model. See individual model information page for details. 18 Installation & Operation Manual Copyright © Puretec Pty Ltd 2024...
- Page 19 6” between the fitting and solder joints when soldering pipes. Failure to do this could cause heat damage to the fittings. This should be carried out by a qualified tradesperson. FOLLOW LOCAL PLUMBING CODES. Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide...
- Page 20 Take the Puretec label, and position it on the front of the vessel as shown in the diagram. 20 Installation & Operation Manual Copyright © Puretec Pty Ltd 2024...
-
Page 21: Programming
Displays total volume in cubic metres since last reset. If metre is not used this display will be shown but '0' will be displayed. Press ▼ for 3 seconds to reset to 0. Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide... - Page 22 Step 3. Press 'REGEN' to exit the system setup. Choose the brine direction using ▲ or ▼. This screen is not viewed when Step 2 is set to filtering. Press 'NEXT' to go to step 4. 22 Installation & Operation Manual Copyright © Puretec Pty Ltd 2024...
- Page 23 Select the time for the third cycle using ▲ or ▼. Set to 'OFF'. Press 'NEXT' to go to step 8. Select the time for the forth cycle using ▲ or ▼. Set to 'OFF'. Press 'NEXT' to go to step 9. Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide...
- Page 24 I-STOP-X70 & I-STOP-Z70 systems. Press 'NEXT' to go to Step 12. I-STOP-X70 & I-STOP-Z70 12. Set regeneration time options to 'NORMAL' using ▲ and ▼. Press 'NEXT' to go to Step 13. 24 Installation & Operation Manual Copyright © Puretec Pty Ltd 2024...
- Page 25 To enter the installer display settings press 'NEXT' and ▲ simultaneously for about 5 seconds and release. Set the day override volume capacity to '3' using ▲ and ▼. Press 'NEXT' to go to Step 3. Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide...
-
Page 26: Power Loss
▼. Press 'NEXT' to exit installer display settings. Power Loss Your Puretec electronic control valve maintains the time for up to 8 hours using the internal PCB battery if power is interrupted. Nonvolatile memory stores the stats & programming & are not affected by power outages. -
Page 27: Regeneration
If necessary a pliers can be used to unscrew the nut or cap. Do not use a pipe wrench to tighten or loosen nuts or caps. Do not place screwdriver in slots on caps and/or tap with a hammer. Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide... - Page 28 As needed. Replace the cartridge if the colour Air Dryer Replacement Cartridge to WTV4125 changes to pink or if the water starts dripping suit WTV4124 from the air dryer outlet. 28 Installation & Operation Manual Copyright © Puretec Pty Ltd 2024...
-
Page 29: Replace The Backup Battery
The battery should be replaced annually or after extended periods without power. Replacement batteries can also be ordered using code: BA-CR2032 through your local Puretec dealer. 1. Turn off the power to the unit and remove If swallowed, a lithium button bettery can cause severe or fatal injuries within 2 hours. -
Page 30: Bypass Valve Operation - Optional Accessory
EXITS ENTERS EXITS ENTERS Diagnostic Mode Shut Off Mode SUPPLY WATER IS SHUT OFF SUPPLY WATER SUPPLY WATER FROM THE HOUSE ENTERS EXITS NO WATER EXITS & THE VALVE 30 Installation & Operation Manual Copyright © Puretec Pty Ltd 2024... -
Page 31: Troubleshooting Guide
C. Time of regeneration set C. Reset regeneration time. incorrectly. Time of day flashes on and A. Power outage(s). A. Reset time of day, replace battery off. (CR2032) and then perform a ‘dry’ reset. Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide... - Page 32 B. Check program settings or diagnostics for to high water usage. abnormal water usage. C. Fouled media bed. C. Clean/replace media. D. Water quality D. Test water and contact Puretec for fluctuation. assistance. H. Leak from seal/spacer H. Clean/replace spacer stack assembly. stack assembly.
- Page 33 PC board. supplied. Press NEXT and REGEN buttons for 3 seconds to resynchronize software with piston position or disconnect power supply from PC Board for 5 seconds and then reconnect. Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide...
-
Page 34: Warranty
Puretec’s discretion, including chargeable inspection and labour costs incurred. Warranty/Australia This warranty is given by Puretec Pty Ltd, ABN 44 164 806 688, 37-43 Brodie Road, Lonsdale SA 5160, telephone no. 1300 140 140 and email at sales@puretec.com.au. - Page 35 Copyright © Puretec Pty Ltd 2024 I-STOP Series User Guide...
- Page 36 MAR2024...
