Summary of Contents for Puretec CFS 2CI Series
- Page 1 User Guide 2CI Commercial Filter Series CFS / IRS / IRX / SFS Water Treatment Systems For correct operation & installation, it is essential to observe these instructions. APR2020...
-
Page 2: Table Of Contents
Warranty ................................27 Puretec Customer Service Thank you for purchasing a Puretec Water Treatment System. Your system is a proven performer manufactured from only quality materials and components. It will give years of reliability and trouble free operation if maintained properly. -
Page 3: Installation Record
TDS (Total Dissolved Salts): ___________ ppm / mg/L Conductivity: ___________ EC / uS/cm Chloride: ___________ ppm / mg/L Sodium: ___________ ppm / mg/L Tannin: ___________ NTU Colour: ___________ HU Copyright © Puretec Pty Ltd 2020 2CI Commercial Filter Series User Guide... -
Page 4: Before Installation
• Install as close as possible to a drain. • Install in correct relationship to other water treatment equipment. Contact Puretec for assistance. • Install the system in the supply line BEFORE the water heater. Temperatures above 40°C (104°F) will damage the system and void the warranty. - Page 5 If lawn sprinklers, a swimming pool, or geothermal heating/cooling or water for other devices/activities are to be treated by the filter system, a larger model MUST be selected to accommodate the higher flow rate, treated water volume, plus the backwashing requirements of the filter system. Contact Puretec for assistance. WARNINGS •...
-
Page 6: Specifications
2040 mm 1" IRX100-2CI SFS150-2CI CFS180-2CI IRS150-2CI 610 mm 2230 mm 1½" IRX150-2CI SFS250-2CI CFS220-2CI IRS250-2CI 762 mm 2170 mm 1½" IRX250-2CI SFS350-2CI CFS320-2CI 914 mm 2338 mm 1½" IRS350-2CI IRX350-2CI Installation & Operation Manual Copyright © Puretec Pty Ltd 2020... -
Page 7: Exploded Diagram
WTV7330 (see model specs on page 6) WTV7200 Valve Cover WTV5135 Transformer, Suit Auto Valve WTV5180 Spanner WTV7220 Spacer Stack* WTV7250 2CI Filter Circuit Board* *Not shown, pre-installed. Copyright © Puretec Pty Ltd 2020 2CI Commercial Filter Series User Guide... -
Page 8: Parts Identification
Parts Identification Diagram Identification Inlet 2" Outlet 2" Drain 1" or 1½" (see model specs on page 6) Control Panel Installation & Operation Manual Copyright © Puretec Pty Ltd 2020... -
Page 9: Installation Procedure
Refer to page 6 for the correct size for your model. Testing & Analysis Ensure water has been tested, Input values into Table on page 4 and the analysis has been inspected by Puretec. Water Analysis Information Hardness ___________ ppm / mg/L... - Page 10 Top up tank with water. Screw valve onto the tank (hand tight is usually sufficient), making sure the distributor tube is properly inserted into the valve. 10 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020...
- Page 11 Connect drain to sewer or storm water, whichever is approved by local authority for discharge water. Ensure drain line has an adequate air gap. 1"DRAIN 1½" DRAIN Drain size/connection dependent on model (see page 6). Copyright © Puretec Pty Ltd 2020 2CI Commercial Filter Series User Guide...
-
Page 12: Programming
▼ buttons. The default time is 2:00. This display will show "REGEN on 0 m3" if "on 0" is selected in Set Regeneration Time Option in Advanced Programming. Press "NEXT" to go to the next step. 12 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020... - Page 13 The system runs through the steps automatically and will reset itself to provide treated water when the regeneration has been completed. Copyright © Puretec Pty Ltd 2020 2CI Commercial Filter Series User Guide...
- Page 14 Current Time (minutes): Set the minutes of the day using ▲ or ▼. Press "NEXT" to exit Set Clock. RETURN TO NORMAL MODE RETURN TO NORMAL MODE RETURN TO NORMAL MODE 14 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020...
-
Page 15: Advanced Programming
Select the Time for the Second Cycle using ▲ or ▼. Press "NEXT" to go to the next step. Select the Time for the Third Cycle using ▲ or ▼. Press "NEXT" to go to the next step Copyright © Puretec Pty Ltd 2020 2CI Commercial Filter Series User Guide... - Page 16 • Off: If set to "oFF", steps 8 & 9 will not be shown. Press "NEXT" to go to the next step. 16 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020...
- Page 17 • Off: If set to "oFF", steps 12 & 13 will not be shown. Press "NEXT" to go to the next step. Copyright © Puretec Pty Ltd 2020 2CI Commercial Filter Series User Guide...
-
Page 18: Dp Switch Programming (Optional)
STEP 2CS 2. Preset to default. Press NEXT to go to step 3. STEP 2CS STEP 2CS STEP 7CS STEP 7CS STEP 7CS STEP 8CS 18 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020 STEP 3CS... - Page 19 • HoLd: If the dP switch is closed a regeneration will be prevented from occurring while there is switch closure. Press NEXT to go to step 6. Copyright © Puretec Pty Ltd 2020 2CI Commercial Filter Series User Guide...
- Page 20 STEP 12CS 9. Preset to default. Press NEXT to return to normal mode. STEP 9CS STEP 10CS RETURN TO NORMAL MODE STEP 10CS STEP 11CS STEP 11CS STEP 12CS 20 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020...
-
Page 21: Start-Up
This valve is factory set to regenerate every third day. The required frequency of regeneration is dependant on the level of contaminates and the amount of water used. To change the regeneration setting refer to the ‘Programming’ section. Copyright © Puretec Pty Ltd 2020 2CI Commercial Filter Series User Guide... -
Page 22: Media Replacement
RMK-SFS350 Order Code: Call the Puretec Customer Service Helpline on 1300 140 140 (AU) and 0800 130 140 (NZ) for more details. The nuts and caps are designed to be unscrewed or tightened by hand or with the special plastic spanner provided. -
Page 23: Troubleshooting Guide
Verify meter cable wires are is flowing. into three pin connector. installed securely into three pin connector labelled METER. Defective meter. Replace meter. Defective PC board. Replace PC board. Copyright © Puretec Pty Ltd 2020 2CI Commercial Filter Series User Guide... - Page 24 Damaged seal/stack assembly. Replace seal/stack assembly. Control valve body type and piston Verify proper control valve body type type mix matched. and piston type match Fouled media bed. Replace media bed. 24 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020...
- Page 25 Main drive gear too tight. Loosen main drive gear. Conduct a dry reset. Improper voltage being delivered to Verify that proper voltage is being PC board. supplied. Conduct a dry reset. Copyright © Puretec Pty Ltd 2020 2CI Commercial Filter Series User Guide...
- Page 26 (stalled) while looking and check MAV/ NHBP black drive for proper park position. pinion on motor for being jammed into motor body. Conduct a dry reset. 26 Installation & Operation Manual Copyright © Puretec Pty Ltd 2020...
-
Page 27: Warranty
Puretec’s discretion, including chargeable inspection and labour costs incurred. Warranty/Australia This warranty is given by Puretec Pty Ltd, ABN 44 164 806 688, 37-43 Brodie Road Lonsdale SA 5160, telephone no. 1300 140 140 and email at sales@puretec.com.au.
