User Guide
RO Series
Reverse Osmosis Undersink Water Filter Systems
For correct operation & installation, it is essential to observe these instructions.
APR2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RO Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Puretec RO Series

  • Page 1 User Guide RO Series Reverse Osmosis Undersink Water Filter Systems For correct operation & installation, it is essential to observe these instructions. APR2020...
  • Page 2: Table Of Contents

    This product contains a button battery. Accidental ingestion may occur and can be fatal. Please keep out of reach from infants. If you suspect an accidental ingestion please contact emergency services. Installation & Operation Manual Copyright © Puretec Ltd 2020...
  • Page 3: Introduction

    Customer Service Help line 1300 140 140 (Australia) 0800 130 140 (New Zealand). Operation The Puretec RO series system is designed to run economically for many years, dependent on the initial installation and periodical maintenance. Flush systems for 10 minutes after any period of non-use more than 2 days. For a period of non-use of 2 weeks or more, it may be necessary to replace cartridge.
  • Page 4: System Installation

    Alternative fittings may be required if being connected to anything other than 15 mm (½”) copper pipe. No electrical or drainage requirements needed. Parts Included RO System Faucet MC051 Cartridge CB951 Cartridge RO Membrane Tank Spanner Multivalve Drain Clamp SmartTee Shut Off Valve Installation & Operation Manual Copyright © Puretec Ltd 2020...
  • Page 5: Cartridge Installation

    The Reject water is usually dispensed down the drain although it can be directed to the garden if desired. To be environmentally friendly, the Puretec RO system has a built in shut off valve so that when the storage tank is full it stops producing water.
  • Page 6 18 - 24 months, depending on incoming water quality. For best performance use only genuine Puretec replacement cartridges and cartridges that are suitable for this system. NOTE: When removing the membrane from the packaging, only remove the outer shrinkwrap packaging, DO NOT remove any other packaging from the membrane.
  • Page 7: Parts Diagram

    Parts Diagram Figure 1 - Parts Diagram BLACK TUBE TANK TANK BLUE TUBE GREEN TUBE YELLOW TUBE MAINS WATER SEDIMENT CHEMICAL MINIMUM 30MM CLEARANCE FOR CARTRIDGE CHANGES. CODE DESCRIPTION KASV47 SMART TEE™ ½”M X ½”F X 1/4”T KTU4G GREEN FLEXIBLE TUBING PVM43PH PRESSURE LIMITING VALVE KTU4G...
  • Page 8: Battery Installation

    5. Red light flashes indicates your cartridges are due to be changed (usage has exceeded contact emergency services. 3,000 minutes or 12 months). Please change the battery when changing the cartridges. Installation & Operation Manual Copyright © Puretec Ltd 2020...
  • Page 9: Quick Connect Fittings

    Quick Connect Fittings Figure 3 - SmartTee™ Quick Connect Fitting Turn the quick connect nut on the SmartTee™ Cut the tube square and push into into the tube stop anticlockwise to release the collet. (inside the collet). For metal tube; remove burrs and chamfer tube end to prevent O-ring seal being damaged.
  • Page 10: Cartridge Changeout

    NOTE: When removing the membrane from the packaging, only remove the outer shrinkwrap packaging, DO NOT remove any other packaging from the membrane. Restore water supply & check for leaks, rectifying them before leaving the unit. 10 Installation & Operation Manual Copyright © Puretec Ltd 2020...
  • Page 11: Use Guidelines

    Use Guidelines Use Guidelines • Operating pressure 300 - 520 kPa. • Ideal tank prressure when empty 34 - 48 kPa (5 - 7 psi). • Operating temperature 0 - 30 °C (protect from freezing). • Maximum flow 270 litres per day. •...
  • Page 12: Warranty

    Applicable to all above, is that the warranties need to be approved by Puretec to ensure product was not incorrectly used, installed or claimed. False and incorrect claims will be pursued at Puretec’s discretion, including chargeable inspection and labour costs incurred.
  • Page 13 Warranty Warranty/Australia This warranty is given by Puretec Pty Ltd, ABN 44 164 806 688, 37-43 Brodie Road, Lonsdale SA 5160, telephone no. 1300 140 140 and email at sales@puretec.com.au. This warranty is provided in addition to other rights and remedies you have under law: Our goods come with guarantees which cannot be excluded under the Australian Consumer Law.
  • Page 14 This page was intentionally left blank. 14 Installation & Operation Manual Copyright © Puretec Ltd 2020...
  • Page 15 This page was intentionally left blank. Reverse Osmosis Undersink Water Filter Systems...
