P30 and S30 Low Voltage VSD
Status Cause
Flashes The option module is operating
Green normally, but is not transferring I/O data
to a controller.
Steady The option module is operating normally
Green and is transferring I/O data to a
controller.
E.3

NET A STATUS INDICATOR

This red/green bicolor status indicator indicates the status for the network connection as shown in this table.
Status Cause
Off The option module is not powered.
The option module is not properly
connected to the network. The
option module has not acquired its
network configuration (IP address,
subnet mask, gateway address)
from the BOOTP/DHCP server.
Flashes Red The I/O connection has timed out.
Steady Red A duplicate IP address fault has
been detected.
The DHCP lease has expired.
Flashes The option module is operating
Green normally but does not have any CIP
connections (I/O or MSG).
Steady Green The option module is operating
normally and has at least one CIP
connection (I/O or MSG).
Appendix E:VSD Dual-port Ethernet/IP Option Module Status Indicator
Corrective Action
• Place the scanner in RUN mode.
• Program the controller to recognize and transmit
I/O to the option module.
• Configure the option module for the program in
the controller.
• Normal behavior if no I/O is being transferred.
No action required
Corrective Actions
• Securely connect and ground the option module
to the drive by fully inserting it into the drive port.
Tighten the two captive screws of the module to
the recommended torque.
• Correctly connect the Ethernet cable to the
Ethernet connector.
• Set a unique IP address with the option module
rotary switches, option module parameters, or a
BOOTP or DHCP server.
• Apply power to the drive.
• Place the controller in RUN mode or apply
power to the peer device that sends I/O.
• Check the IGMP Snooping/Ethernet Switches
for correct operation.
• Check the amount of traffic on the network.
Configure the option module to use a unique IP
address and cycle power.
• Place the controller in RUN mode, or apply
power to the peer device that sends I/O.
• Program the controller or peer device to
recognize and transmit I/O or make a message
connection to the option module.
• Configure the option module for the program in
the controller or the I/O from the peer device.
No action required
