P30 and S30 Low Voltage VSD
Status Cause
Steady The drive has refused an I/O
Red connection from the adapter.
Another DPI peripheral is using
the same DPI port as the
adapter.
Steady The adapter is connected to a
product that does not support
Orange
DPI communications.
Flashing The adapter is establishing an
Green I/O connection to the drive.
The adapter is properly
Steady
connected and is communicating
Green
with the drive.
D.2 MOD STATUS INDICATOR
This red/green bicolor LED indicates the status of the adapter as shown in the table below:
Status Cause
Off The adapter is not powered or is
not properly connected to the
drive.
Flashing The adapter has failed the
Red firmware test.
The adapter is being flash
upgraded.
Steady The adapter has failed the
Red hardware test.
Flashing The adapter is operational but is
Green not transferring I/O data.
Steady The adapter is operational and
Green transferring I/O data.
D.3 NET A STATUS INDICATOR
This red/green bicolor LED indicates the status of the network connection as shown in the table below:
Status Cause
Off The adapter is not powered,
the adapter is not properly
connected to the network, or
Appendix D:VSD Modbus/TCP Adapter Status Indicator
Corrective Action
Important: Cycle power to the drive (or adapter if
mounted in a DPI External Comms Kit) after making any
of the following corrections.
•
Verify that all DPI cables on the drive are securely
connected and not damaged. Replace cables if
necessary.
•
Verify that the DPI drive supports Datalinks.
•
Configure the adapter to use a Datalink that is not
already being used by another peripheral.
Connect the adapter to a compatible product that
supports DPI communications.
No action required. Normal behavior if no DPI I/O is
enabled
No action required
Corrective Action
• Securely connect the adapter to the drive using the
Internal Interface (ribbon) cable.
• Apply power to the drive (or adapter if mounted in a DPI
External Comms Kit).
• Clear faults in the adapter.
• Cycle power to the drive (or adapter if mounted in a DPI
External Comms Kit).
• If cycling power does not correct the problem, the
adapter parameter settings may have been corrupted.
Reset defaults and reconfigure the adapter.
• If resetting defaults does not correct the problem, flash
the adapter with the latest firmware release.
• Cycle power to the drive (or adapter if mounted in a DPI
External Comms Kit).
• Replace the adapter.
• Verify that the controller can send messages to the
adapter.
• Normal behavior if no DPI I/O is enabled.
No action required.
Corrective Actions
• Securely connect the adapter to the drive using the
Internal Interface (ribbon) cable and to the network
using an Ethernet cable.
