P30 and S30 Low Voltage VSD
Tool Description
Combination wrench
Phillips screw
driver/bit
Pozidriv
Torque wrench
Torque wrench
Other equipment or tools generally used in start-up are listed in the VSD Tools Kit (PN 100072064). Items
can be selected from this list and ordered through

8.2 PRE-POWER UP CHECKS FOR INITIAL STARTUP

Potential Severity: Major
Potential Loss:
Hazard Category: Electrical, Explosives
Use appropriate lockout/tagout procedures (refer to SEN-HSE-S027) to ensure that VSD power is OFF
before proceeding with the following checks and procedures.
Use a Volt Ohm Meter (VOM) to verify that ALL power is OFF on the VSD, including
• incoming line at the bottom of the circuit breaker
• motor terminals
the DC bus
•

8.2.1 INSTALLATION CHECKLIST

Complete the following installation checks before you start up the drive.
Item
No.
1 The ambient operating conditions meet the specifications.
The drive cabinet has been fixed to floor. If necessary because of vibration or
2
other causes, check that the cabinet is also fixed at the top to the wall or roof.
3 The cooling air will flow freely in and out of the drive cabinet.
If the drive has been stored over one year, verify that the electrolytic DC
4 capacitors in the DC link of the drive have been reformed. Refer to
Reforming the
There is an adequately sized protective earth (ground) conductor between the
drive and the switchboard, and the conductor has been connected to an
5
appropriate terminal, and the terminal has been tightened. (Pull the conductor to
check.) Proper grounding has also been measured according to the regulations.
The input power cable has been connected to the appropriate terminals, the
6 phase order is right, and the terminals have been tightened. (Pull the conductors
to check.)
Details
10 mm, 17 mm
#2, 492-C
#2, M3 x 7
1...12 N•m (8.8...106 lb•in)
6...50 N•m (53...443 lb•in)
Assets, Personnel
Description
Capacitors.
Section 8:Start-up and Commissioning
Lift Control Systems.
Check ()
