P30 and S30 Low Voltage VSD

Section 3: Inspection/Storage/Disposal

This section describes how to inspect a VSD when it first arrives at the wellsite or jobsite, how to ship or
store the unit if it will not be immediately connected and put in service, and how to dispose of any old or
previously installed electrical/electronic drive equipment.

3.1 INSPECTION OF NEW UNIT

1. Immediately upon receipt of the drive it should be un-crated and a thorough visual inspection for damage
should be made.
2. Check the unit for loose, broken, bent, or otherwise damaged parts due to shipping.
3. Check to see that the rated capacity and the model number specified on the nameplate conform to the
order specifications.
4. Shut and seal the drive door before storing or shipping. Ensure there are no openings in the drive for
moisture or dust to enter.

3.2 STORAGE AND SHIPPING

For packaging and international shipping requirements, refer to
storage and shipment refer to the steps below:
1. Store the unit and any optional equipment in a clean, dry, and well-ventilated location. The VSD must be
stored and shipped upright.
2. Avoid storage in locations with high humidity and dust. It is highly recommended to store drives indoors.
If for any reason, the drive cannot be stored inside, it should not be left outside for more than 30 days.
3. Spare part PCBs are to be stored in anti-static packages in a dry environment.
4. Drives should be stored and shipped with all inspection plates and doors properly closed, including the
C-clamps surrounding the door frame.
5. Drives that have been running or opened for inspection must have a dry interior before shipping or
storing. Dry the cabinet in any appropriate fashion including using heaters. Do not heat components over
140 degF (60 degC) while drying. After the drive is dry, it is optional to add desiccants or corrosion
inhibitor packages. Shut and seal the drive doors. Protective external wrapping is required to keep the
drive clean on the exterior or to prevent abrasions during shipping.
6. The capacitors must be reformed if the drive has been stored for a year or more. Refer to
Reforming the Capacitors
7. The following shipping and storage environmental conditions should not be exceeded:
Outdoor Drives: -40 degF (-40 degC ) to 158 degF (70 degC) for shipping and storing
8. The drive should be warmed to 5 degF (-15 degC) before connecting power and running a load.

3.3 DISPOSAL

Lithium batteries MUST be removed from the drive and motor controller prior to disposal of the unit. The
batteries MUST be disposed of separately and according to local regulations.
The circuit boards and display module of the drive and motor controller used in this equipment may contain
lead solder and solder paste. The boards should be disposed of according to local regulations.
Please contact your local environmental agency or Sensia HSE advisor for details on proper disposal of
electrical components and packaging in your particular area.
for more details.
Section 3:Inspection/Storage/Disposal
InTouch Content ID
5170246. For general
10.6
