P30 and S30 Low Voltage VSD Section 6:Operator Interface
If you would rather see the Process screen (shown below) as the initial power-up screen, change the HIM
Parameter 03 - [Initial Screen] value to '1' (Process Scrn). By default, when the HIM keys are not used for
the time period set in Parameter 07 - [User Dspy Time], the screen being displayed at that time will revert
back to the initial screen. You can disable this feature by setting Parameter 06 - [User Dspy Enable] to '1'
(Disable).
6.1.5.2 Process Screen
Note
The PowerFlex 755T inverter module does not fully support Process Display text.
To display the Process screen, press the ESC soft key on the Status screen (below). The Process screen
shows various drive monitoring parameters. Multiline and single-line views can be selected by pressing the
VIEW soft key. The displayed default monitoring parameters can be changed.
