Chapter 4: Installing, Removing, and Replacing FRUs
Replacing the Y-tray with Robot
160
13 Place your index fingers under the two designated lift tabs on the
front and rear of the Y-tray (see
stickers on them to identify them. Gently lift the Y-tray up until it is
disengaged from the gears. Lift the Y-tray out of the library and set
it down carefully on a flat, level surface.
Caution: Lift the Y-tray only by the two designated lift tabs. Lift
up at both locations simultaneously and keep the Y-
tray level as you lift. Do not tilt or twist the Y-tray.
Figure 73). The lift tabs have orange
