FIBARO ROLLER SHUTTER 4 Operating Manual page 8

14
Monostable switches - hold to move
Example of the switch design:
Parameter Devices
Roller
blind,
awning,
20 – Switch
pergola,
type
curtain,
Venetian
blind
Roller
blind,
awning,
pergola,
curtain
151 –
Operating
mode
Venetian
blind
Favorite position – available
If you hold down the switch longer than slats movement time + additional
4 seconds (default 1.5 s + 4 s = 5.5 s) the device goes to the limit
position.
In that case releasing the switch does nothing.
Available
Description
values
1 - monostable This parameter determines
switches – hold which mode S1 or S2 inputs
to move operate with.
0 • 1 x click of the switch –
10% up movement
• 1 x click of the switch –
10% down movement
• 2 x click of the or
switch – favorite position
• hold the switch – up
movement until release
• hold the switch – down
movement until release
1 (0-90°) • 1 x click of the switch
– slats rotate up by the
or
predefined step
2 (0-180°)
• 1 x click of the switch
– slats rotate down by the
predefined step
• 2 x click of the or
switch – favorite position
• hold the switch – up
movement until release
• hold the switch – down
movement until release
Single monostable switch
Example of the switch design:
Available
Parameter Devices
values
Roller 1 – single
blind, monostable
awning, switche
20 – Switch
pergola,
type
curtain,
Venetian
blind
0
Roller
blind,
awning,
pergola,
curtain
151 –
Operating
mode
1 (0-90°)
or
2 (0-180°)
Venetian
blind
Favorite position – available
Description
This parameter determines
which mode S1 or S2 inputs
operate with.
• 1 x click – initiate
movement to the limit
position
• next click – stop
• one more click – initiate
movement to the opposite
limit position
• 2 x click – favorite position
• hold – initiate movement
until release
• 1 x click – initiate
movement to the limit
position
• next click – stop
• one more click – initiate
movement to the opposite
limit position
• next click – stop
15
