Three-state switch
Example of the switch design:
Parameter Devices
Roller
blind,
awning,
20 – Switch
pergola,
type
curtain,
Venetian
blind
Roller
blind,
awning,
151 – pergola,
Operating curtain
mode
Venetian
blind
Favorite position – unavailable
Available
Description
values
5 – three-state This parameter determines
switch which mode S1 or S2 inputs
operate with.
0 1 x click – initiate movement
to the limit position in the
selected direction until the
switch selects the stop
command
1 (0-90°)
or
2 (0-180°)
Favorite position
Your device has a built-in mechanism for setting favorite positions.
You can activate it by double-clicking on the monostable switch(es)
connected to the device or from the mobile interface (mobile App).
Favorite roller blind position
You can define the favorite position of the blinds. It can be set with
parameter 159. The default value is set to 50%.
Favorite slats position
You can define the favorite position of the slats angle. It can be set with
parameter 160. The default value is set to 50%.
Pot protection
Your device has a built-in mechanism to protect, for example, flowers on
the windowsill.
This is the so-called virtual limit switch.
You can set its value with parameter 158.
The default value is 0 - meaning that the roller blind moves between the
maximum end positions.
LED indicators
The built-in LED shows the current status of the device. When the device
is powered:
Green - the device added to the Z-Wave network (non-secure,
S0, S2 not Authenticated)
Magenta - the device added to the Z-Wave network (Security S2
Authenticated)
Red - the device not added to the Z-Wave network
Blinking cyan - Update in progress
