11: Energy metering

The device enables the energy consumption monitoring. Data is sent to the
main Z-Wave controller.
Measuring is carried out by the most advanced micro-controller technology,
assuring maximum accuracy and precision (+/- 5% for loads greater than
10W).
Electric energy – energy consumed by a device through a
!
time period. Consumers of electricity in households are billed
by suppliers on the basis of active power used in given unit of
time. Most commonly measured in kilowatt-hour [kWh]. One
kilowatt-hour is equal to one kilowatt of power consumed over
period of one hour, 1kWh = 1000Wh.
Resetting consumption memory:
The consumption memory reset can be initiated through the BUI.
The consumption memory reset is also carried out, during the reset to
factory defaults procedure.

12: Configuration

Association (linking devices) – direct control of other devices within the
Z-Wave system network.
Associations enable:
• reporting the device status to the Z-Wave controller (using the Lifeline
group),
• creating simple automations by controlling other devices without
participation of the main controller (using groups assigned to actions
on the device).
Commands send to the 2 association group reflect button
nd
i
operation according to the device configuration, e.g. starting
the blinds movement using the button sends frame responsible
for the same action.
The device provides the association of 2 groups:
The 1 association group – "Lifeline" reports the device status and
st
allows for assigning a single device only (main controller by default).
The 2 nd association group – "Window Covering" is intended for
curtains or blinds allowing the user to control the amount of light going
through windows.
The device enables to control 5 regular or multichannel devices per an
association group, with the exception of the Lifeline group which is reserved
solely for the controller and hence only 1 node can be assigned.
To add an association:
1. Go to Settings .
2. Go to Devices.
3. Select the relevant device from the list.
4. Select the Associations tab.
5. Specify a group and devices to associate with.
6. Save your changes.
