5: Adding to the Z-Wave network
Adding (Inclusion) – the Z-Wave device learning mode enabling you to add
the device to the existing Z-Wave network.

5.1: Adding manually

To add the device to the Z-Wave network manually:
1. Power the device. If the device isn't added to the Z-Wave network, the
device LED indicator glows red.
2. Set the main controller in the (Security/non-Security) add mode (for more
information, see the controller manual).
3. Quickly, click the PROG button on the device three times. Alternatively,
click quickly S1 or S2 three times.
4. If you're adding the device in the Security S2 Authenticated mode, input
the PIN Code, which is labelled on the device. The PIN Code is also an
underlined part of the device specific key (DSK) labelled at the bottom of
the box.
5. Wait for the LED indicator to blink yellow.
6. Successful adding is confirmed by the Z-Wave controller message and
the device LED indicator:
Green – successful (non-secure, S0, S2 non-authenticated)
Magenta – successful (Security S2 Authenticated)
Red – not successful

5.2: Adding using SmartStart

SmartStart solution enables products to be added into the Z-Wave network
by scanning the Z-Wave QR Code present on the product with a controller
providing SmartStart inclusion. A SmartStart product is added automatically
within 10 minutes of being switched on in the network range.
To add the device to the Z-Wave network using SmartStart:
1. To use the SmartStart solution your controller needs to support Security
S2 mode (for more information, see the controller manual).
2. Enter the full DSK string code to your controller. If your controller is capable
of QR scanning, scan the QR code placed on the label.
3. Power the device (turn on the mains voltage).
4. The LED indicator starts blinking yellow, wait for the adding process to
end.
5. Successful adding is confirmed by the Z-Wave controller message and
the device LED indicator:
Green – successful (non-secure, S0, S2 non-authenticated mode),
Magenta – successful (Security S2 Authenticated mode),
Red – not successful
In case of problems with adding the device, please reset the
i
device and repeat the adding procedure.
6: Removing from the Z-Wave network
Removing (Exclusion) – the Z-Wave device learning mode enabling you
to remove the device from the existing Z-Wave network.
To remove the device from the Z-Wave network:
1. Make sure the device is powered.
2. Set the main controller in the remove mode (for more information, see
the controller manual).
3. Quickly, click the PROG button three times. Alternatively, click quickly
S1 or S2 three times within 10 minutes of powering up the device.
4. Wait for the removing process to end.
5. Successful removing is confirmed by the Z-Wave controller message.
6. The device LED indicator glows red.
Removing the device from the Z-Wave network doesn't cause factory
i
reset.
