FIBARO ROLLER SHUTTER 4 Operating Manual page 16

30
Parameter Description
This parameter enables
reversing the operation
25 –
of O1 and O2 without
Outputs
changing the wiring
orientation
(e.g. in case of invalid
motor connection).
40 – First
This parameter
button –
determines which
scenes sent
actions result in sending
scene IDs assigned to
them. Values can be
combined (e.g. 1+2=3
means that scenes for
41 – Second
single and double click
button –
are sent).
scenes sent
To start automatic
calibration, select the
value 3. When the
calibration process
is successful, the
parameter takes
the value 1. When
automatic calibration
150
fails, the parameter
– Calibration
takes the value 2.
If the transitions times
for the device are
changed manually
using the parameter
(156/157), the
parameter 150 takes
the value 4.
This parameter enables
you to adjust the
operation, depending
on the connected
151 –
device.
Operating
mode
In the case of venetian
blinds, the angle of
rotation of the slats
must also be selected.
For Venetian blinds the
parameter determines
152 –
the time of a full turn
Venetian
cycle of the slats.
blind - slats
full turn
The parameter is
time
irrelevant to other
modes.
Default Available
Size
Value Values
0 - default (O1 – UP,
O2 – DOWN)
0 (default
1 [byte]
value)
1 - reversed (O1 –
DOWN, O2 – UP)
0 - No scene active
1 – Key pressed 1
time
15 (All 2 – Key pressed 2
1 [byte] scenes times
active)
4 – Key pressed 3
times
8 – Key hold down
and key released
0 - Device is not
calibrated
1 - Autocalibration
successful
0 (default
1 [byte] 2 - Autocalibration
value)
failed
3 - Calibration
process
4 - Manual calibration
0 – Roller blind,
Awning, Pergola,
Curtain
0 (default
1 [byte] 1 – Venetian blind
value)
90°
2 – Venetian blind
180°
0-65535 (0 -
15 (1.5
2 [byte] 6553.5s, every 0.1s)
seconds)
- time of turn
Parameter Description Size
The parameter should
be modified only when
using electric curtains
154 - Delay
or low-power motors!
for power
detection 2 [byte]
This parameter should
after the
be used when the
motor start
engine slowly increases
power consumption at
start-up.
The parameter should
be modified only when
using electric curtains
155 - Motor
or low-power motors!
operation
2 [byte] 2 (2 W)
detection
The power threshold is
interpreted as reaching
the limit switch.
This parameter
determines the time
needed to reach the full
opening.
156 – Time
The value is set
of up 2 [byte]
automatically during
movement
the calibration process.
It should be manually
set in case of problems
with the autocalibration.
This parameter
determines the time
needed to reach full
closure.
157 – Time
The value is set
of down 2 [byte]
automatically during
movement
the calibration process.
It should be manually
set in case of problems
with the autocalibration.
Default Available
Value Values
10
0 - 255 (0 - 25.5
seconds)
(1second)
0 - reaching the limit
switch isn't detected.
In this case parateter
150 Calibration is
set to 4 - Manual
calibration.
You need to correct
the time manually with
parameters 156 and
157.
1 - 255 (1 - 255 W) -
report interval
0 - 65535
600 (60
(0 - 6553.5 s, every
seconds)
0.1 s) - time of turn
0-65535
600 (60
(0 - 6553.5 s, every
seconds)
0.1 s) - time of turn
