AMP Research Power Step 76138-01A Installation Manual page 8

Using a T27 Torx driver start torx bolts and
washers. Snug bolts but do not tighten. Note
on 2013- current models with pre stamped
holes filing may be required if holes do
not line up. Do not shift linkage up to align
bottom holes.
10
17
Using a 13mm wrench tighten two hex bolts on
linkage. Torque to 16 ft-lbs.
10
18
The jogs in the lower part of the linkages point toward one another, as shown, Drive (motor) Linkage in the
Front and Idler Linkage in the Rear. Note: Linkage position described in parts list on page 3.
7
20
www.amp-research.com
A M P R E S E A R C H P O W E R S T E P
13mm
– D O D G E R A M
T M
Using a T27 Torx driver torque bolts to 6 ft-lbs.
19
13mm
8/15
16
15
T27 Torx
16
15
T27 Torx
IM76138 rev 03.02.22
